LawnMaster NPTGSS2617A Service Manual

LawnMaster NPTGSS2617A
45 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #4 background imageLoading...
Page #4 background image
4
SPECIFICATIONS
0XIÀHUWRFUDQNFDVH
7LJKWHQWKHEROW0î/VHFXULQJWKHPXIÀHUWR
crankcase.
62-71 7-8
7LJKWHQWKHVFUHZV0î/VHFXULQJWKHPXIÀHU 62-71 7-8
Carburetor mount to
cylinder
Tighten the screws securing the carburetor mount to
cylinder.
35-44 4-5
$LU¿OWHUEDVHWR
carburetor
Pre-screw the nuts (M5) with washers, and then
tighten.
27-35 3-4
Pawl to crankshaft
Pre-screw the pawl assembly to crankshaft, and then
tighten with pneumatic screwdriver.
106-133 12-15
Fuel Tank to crankcase
Tighten the bolt (M5×10L) securing the fuel tank
bracket to crankcase.
18-27 2-3
Electric starter
assembly to engine
body
Tighten the screws (M5×60) securing the electric
starter assembly to engine body.
27-35 3-4
Flywheel cover to
crankcase
7LJKWHQWKHVFUHZV0îVHFXULQJWKHÀ\ZKHHO
cover to crankcase.
53-64 6-7.2
Lower engine cover
Tighten the screws
securing the lower
engine cover.
First, screw (ST3.5×10), cross
head.
2-4 0.2-0.5
6HFRQGEROWV0îKH[
socket head.
27-35 3-4
Upper engine cover
Tighten the screws (M5×35) securing the upper engine
cover.
27-35 3-4
Spark plug cover to
upper engine cover
Tighten the screws
(M5×10) securing
the spark plug
cover to upper
engine cover.
Screw for spark plug cover. 18-27 2-3
Screw for upper engine cover. 27-35 3-4
Tighten the screw (ST3.5×10) securing the upper and
ORZHUHQJLQHFRYHUVRQPXIÀHUVLGH
9-18 1-2
Assist handle to shaft
Tighten the screw (ST3.9×16F) securing the assist
handle ball socket and joint.
9-18 1-2
Throttle-body set to
shaft
Tighten the self-taping screws (ST3.9×16F) securing
the right and left parts of the main handle.
18-22 2-2.5
Tighten the countersunk head self-taping screws
(ST4.8×7) securing the main handle to shaft.
18-22 2-2.5
Shaft connection
sleeve to upper shaft
(Curved split shaft
NPTGCP2617A only)
Tighten the self-taping screw (ST4.8×8) securing the
shaft connection sleeve to upper shaft.
18-22 2-2.5
7LJKWHQWKHKH[DJRQVRFNHWVFUHZî
securing the shaft connection sleeve.
18-22 2-2.5
LED light panel to
starter switch base
Tighten the screw (ST2.2×6F) securing the LED light
panel to starter switch base.
9-13 1-1.5
Tighten the screw (ST3.9×16F) securing the starter
switch pressing plate and the start button.
9-13 1-1.5
Debris guard
mounting bracket to
shaft (Straight shaft
NPTGSS2617A only)
5HPRYHWKHJHDUER[¿UVW7LJKWHQWKHVFUHZVHFXULQJ
the debris guard mounting bracket to shaft.
13-18 1.5-2
