PARTS AND FEATURES

NPTGCP2617A PARTS LIST

Key

Number

Application Description Quantity

1 321001101 Cleva 26cc 2-Cycle Engine 1

2 321001102 Throttle-body & Starter Set 1

2.1 321001103 Throttle-body Set 1

2.2 321001104 Starter Set 1

2.2.1 321001105 Electric Switch 1

2.2.2 321001106 Starter Switch Assembly 1

2.2.3 321001107 Stop Switch Set 1

2.2.4 321001108 PCB Assembly 1

3 321001109 Handle Spacer 2

4 321001110 Cable Clamp 2

5 321001111 Clutch Assembly 1

5.1 321001112 Bolt 4

6 321001113 Wire Lock 1

7 321001114 7.2V Lithium-Ion Battery 1

8 321002101 Aluminum Upper Trimmer Shaft 1

9 321001116 Assist Handle Assembly 1

9.1 321001117 Assist Handle 1

9.2 321001118 Handle Clasp 1

9.3 321001119 Ball Joint 1

9.4 321001120 Ball Socket 1

10 321002102 Shaft Connection Sleeve 1

11 321002103 Aluminum Lower Trimmer Shaft 1

12 321002104 Cover Plate 1

13 321002105 Debris Guard 1

13.1 321002106 Bolt 1

14 321002107 Bump Feed Trimmer Head Assembly 1

14.1 321002108 Bump Feed Spool Spring 1

15 321001127 Charger 1

16 321001128 Shoulder Strap Clasp (Available Separately) 1
