CONTENTS
PRODUCT SPECIFICATIONS
GENERAL SAFETY RULES
SYMBOLS
KNOW YOUR GRASS TRIMMER
ASSEMBLY
BATTERY PACK AND CHARGER
OPERATION
MAINTENANCE
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
TROUBLESHOOTING
WARRANTY
EXPLODED VIEW
PARTS LIST
EXPLODED VIEW 26CC 2-CYCLE ENGINE
PARTS LIST 26CC 2-CYCLE ENGINE
NOTES
Section Page
2
2
3-6
7-8
9-10
11-13
14-15
16-22
23-30
31
32-33
34
35
36
37
38
39-40
Engine Size
Engine Displacement
Power / Speed
Idle Speed
Max Torque / Speed
Fuel Tank Capacity
Fuel / Oil Ratio
Line Diameter
Cutting Width
Net Weight
Battery Model No.
Battery Type
Charger Model No.
Charger Input
Charger Output
Charging Period (Battery Fully Discharged)
2-Stroke / Full Crank
26cc
0.72 kW / 7500 RPM
3000 RPM
0.9 Nm / 6000 RPM
400ml
40 : 1
0.08" - 0.1" (2.0 mm - 2.54 mm)
17" (432 mm)
13 lbs (5.9 kg)
07LB2001-S
7.2V Lithium-Ion, 2.0 Ah
YLS0042-T084045
100-240V ~ 50/60Hz 0.3A Max
8.4V 450 mA
4-6 Hours
PRODUCT SPECIFICATIONS
26cc-2 CYCLE GRASS TRIMMER
