17
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Electrical Specifications
Important: Qualified and licensed electricians must perform all electrical hookups.
The following specifications must be followed in order to ensure proper performance
and safety.
WARNING:Starting an incorrectly wired spa / hot tub could cause
severe damage to the mechanical equipment or even
bodily harm. Have your licensed electrician verify GFCI
wiring with the schematics on pages 18 - 19 prior to
starting the spa / hot tub or call your local dealer.
CAUTION: Failure to abide by specifications listed may result in
damage to the equipment and will void the warranty.
All spa / hot tubs (except Rejoice) must be wired with a 50 Ampere (Rejoice 40
ampere) breaker (or according to IEE wire regulations for export models). Failure to do
so will cause equipment damage and will not be covered under your guarantee.
All spa / hot tubs must be protected with an over current protective device with built-in
GFCI in the service panel.
Table 2 – Wire Size Chart
CAUTION: Test the GFCI before each use of the spa / hot tub.
* Use only solid copper wire.
Volts
(V)
Freq.
(Hz) Phase
Rating
(A)
GFCI
(A)
Wire size from GFCI
to Main Panel*
# of
Terminals
on plug
240 60 1 32 40
8-3 plus ground (up to 130’)
6-3 plus ground (up to 230’)
4-3 plus ground (up to 360’)
4
Rejoice
Volts
(V)
Freq.
(Hz) Phase
Rating
(A)
GFCI
(A)
Wire size from GFCI
to Main Panel*
# of
Terminals
on plug
240 60 1 40 50
6-3 plus ground (up to 130’)
4-3 plus ground (up to 230’)
2-3 plus ground (up to 360’)
4
Revive, Relieve, Refresh
