3JACKAL
How to access the visor bolts
Jackal has an adjustable visor secured
to the helmet by 2x metal bolts. These
bolts are covered by plastic caps to
retain the clean aesthetic of the helmet.
If the bolts loosen, for example after lots
of vibration due to riding hard on rough
terrain, it may be necessary to tighten
them.
1) To do this, prize the cap o with your
nger nail, or gently with a small at-
headed screwdriver as shown in g.f.
2) When the cover is removed you will
have access to the visor bolts. These
can be tightened clockwise using a
coin, large athead screwdriver or 4mm
hex key as shown in g.g.
g.e
Plastic caps covering the bolts.
g.f g.g
