LCN 4010 SERIES
CYLINDERS
CYLINDER, 4010-3071
Standard, handed cast iron cylinder assembly.
For various applications see “Table of Sizes” on 4010 Series
page 7.
COVERS
COVER, 4010-72
Standard, non-handed plastic cover.
METAL COVER, 4010-72MC
Optional, handed cover. Required for plated finishes and
custom powder coat finishes.
ARMS
REGULAR ARM, 4010-3077
Non-handed arm.
HOLD-OPEN ARM, 4010-3049
Optional, handed arm provides hold-open function,
adjustable at elbow.
FUSIBLE LINK ARM, 4010-3049FL
Optional, handed arm releases hold-open function when
exposed to temperatures above 165° F.
1/8” (3 mm) maximum reveal. NOTE: Check local codes
before specifing FL arms. NOT A LIFE SAFETY PRODUCT!
72
3077
72MC
3071
3049
3049FL
5
