Copyright © 2018 Liquid Combustion Technology, LLC LCT Engine Service Manual: 79, 136, 179, 208, 254, 291, 306, 369, 414 & 420cc 19
414cc Summer Engine Dimensions
*Drawings do not accurately represent actual engine appearance.
22.5
29
17
R13
R7
132
ø12
2-ø10.5
90
400
485
14
106
432
133±0.03
