Copyright © 2018 Liquid Combustion Technology, LLC LCT Engine Service Manual: 79, 136, 179, 208, 254, 291, 306, 369, 414 & 420cc 3
Plant Design Family
Crankshaft
Shaft HP Paint Code Starter Type Options Emissions Label Pack Code
P LM Moderate H Horizontal T Threaded 150
[1.5hp (63cc)]
1 - JPC Black Recoil
(Standard JPC Black)
E - 12VDC/
120VAC Electric
A - Fixed Speed E1 - 50 State S - Single Pack
S LO ***Hybrid V Vertical K Straight-Keyed 175
[ 1.75hp (79cc) ]
2 - Black Tank
(Pantone Black G (Glossy))
P- Recoil B - Manual Choke E2 - 49 State M - Multi-Pack
D LX Extended P Tapered 200
[ 2.0hp (87cc) ]
3 - Titan Yellow Blower Housing Z - Recoil/
Electric Provision
C - Catalytic Muffler E4 - California Preempt
LD Diesel S Splined (No Attach.) 250
[ 2.5hp (98cc) ]
4 - Black Blower Housing (Pantone
Black G (Glossy))
Y - 220VAC Electric D - Generator Air Filter E5 - California Exh Only
W1 GEN I Snow G1 2:1 Reduction (GEAR) 350
[ 3.5hp (106cc) ]
5 - Yellow Recoil
(Pantone 1235C)
X - 12V DC with Starter Box E - Generator Muffler E7 - European Compliant
W2 GEN II Snow G2 6:1 Reduction (GEAR) 400
[ 4.0hp (136cc) ]
6 - Yellow Tank
(Pantone 1235C)
V - [TBD] F - No Tank E8 - Australian Compliant
W3 Single Stage
Snow 1
G3 2:1 Reduction (CHAIN) 500
[ 5.0hp (179cc) ]
7 - Black Tank
(Pantone Black M (Matte))
U - [TBD] G - High Oil Fill Tube E9 - South East Asia
W4 *Snow King G4 2:1 Reduction (CLUTCH) 650
[6.5hp (208cc) ]
8 - Black Blower Housing (Pantone
Black M (Matte))
T - [TBD] H - Commercial Fuel Tank (Large
Fuel Tank)
EA - Canadian Compliant
W5 **Snow King 750
[7.5hp (254cc) ]
9 - Yellow Blower Housing
(Pantone 1235C)
S -[TBD] I - AC Charging Coil Equipped EB - NON CERTIFIED
W6 Private Label
Snow
850
[ 8.5hp (291cc) ]
1A - Titan Green Blower Housing
(Pantone Green 364C)
J - DC Charging Coil Equipped E12 - [TBD]
W7 Ariens Single
Stage
950
[ 9.5hp (306cc) ]
1B - Titan Green Recoil
(Pantone Green 364C)
K - Evaporative Emission Equipped E13 - [TBD]
W8 GEN III Snow 1000
[ 10.0hp (369cc) ]
1D - XH Black Recoil
(Pantone Black M (Matte))
L - Coaxial Idle Down Equipped E14 - [TBD]
ID Inverter Design
Engine
1250
[ 12.5hp (414cc) ]
1C - Carmine Red Blower Housing
(RAL 3002)
M - Remote Throttle Control E15 - [TBD]
1300
[13.0hp (420cc) ]
1E - Blue Recoil
(PMS 294C)
N - High Ouput Air Filter - Non CA
CI219A
[ 4hp (219cc) ]
1F - Blue Fuel Tank
(PMS 294C)
O - Snow Equipped
CI306
[ 6hp (306cc) ]
1G - Blue Blower Housing
(PMS 294C)
P - Pleated Paper Air Filter
CI306A
[ 7hp (306cc) ]
1H - Titan Orange Blower Housing Q - No Low Oil Sensor
CI418
[ 8hp (418cc) ]
1I - Titan Orange Recoil R - Low Temperature Muffler
CI418A
[ 9hp (418cc) ]
IJ - Sliver Recoil
(Titan Spec Silver)
S - Atm. Vented Plastic Fuel Cap w/
Tether Cord
CI219
[ 3.5hp (219cc)]
1K - Sliver Blower Housing
(Titan Spec Silver)
T - Two Low Oil Fill Plugs
CI219A
[4.0hp (219cc)]
1L - [TBD] U - Upgrade Bearing
CI435A
[ 9hp (435cc) ]
1M - [TBD] V - Viton Oil Seals
1N - XH Black Recoil (Pantone
Black G (Glossy)
X - Single Stator Charging System
1O - Yellow Fuel Tank
(PMS B1046)
Y - Dual Stator Charging System
1P - JPC Black Recoil (Lightweight
Recoil Design)
Z - CE Compliance Package
1Q - [TBD] 1 - Integrated On/Off Speed Controls
1R - [TBD] 2 - Remote Choke
1S - [TBD] 3 -2.7L Fuel Tank
1T - [TBD] 4 - 3.6L - Fuel Tank
1U - [TBD] 5 - 60W AC Alternator
1V - [TBD] 6 - ROV Fuel Tank Equipped
1W - [TBD] 7 - Reduced Sound Muffler Package
1X - [TBD] 8 - [TBD]
1Y - [TBD] 9 - Front Oil Drain Tube
1Z - [TBD] 10 - [TBD]
2A - [TBD] 11 - [TBD]
2B - [TBD]
2C - [TBD]
2D - Yellow Recoil (Yellow C)
2E - Yellow Blower Housing
(Yellow C)
2F - Yellow Fuel Tank (Yellow C)
2G - Blue Recoil (PMS 287C)
2H - Blue Blower Housing
(PMS 287C)
2I - Blue Fuel Tank (PMS287C)
2J - [TBD]
2K - [TBD]
2L - [TBD]
2M - [TBD]
2N - [TBD]
2O - [TBD]
2P - [TBD]
Engine Model Number & Serial Numbering System
Model No. PLMHK14650124PBGPSTUVE2M ID Number 920811000
P Manufacturing Facility 9 Horizontal
LM Moderate Design Family 208 cc Displacement
H Horizontal Crankshaft 1 Summer
K Keyed PTO design 1000 Sequential Number
14 #14 Crankshaft Drawing
650 6.5hp (208cc) engine
1 Black Recoil (Glossy)
2G Blue Recoil (PMS287C)
2 Black Tank (Glossy)
4 Black Blower Housing (Glossy)
P Pull Start
B Manual Choke
G High Oil Fill Tube
P Pleated Paper Air Filter
S Atmosphere Vented Plastic Fuel
Cap w/ Tether Cord
T Two Low Oil Fill Plugs
U C&U Bearings
V Viton Oil Seals
E2 49 State Compliant
M Multi-Pack
EXAMPLE
Both Model & ID Numbers to be
on PMI & Specification Sheet
NOTES:
* W4 DESIGNATOR IS USED FOR FULL ENGINE DRESSED SNOW KING PLATFORMS
** W5 DESIGNATOR IS USED FOR LIMITED ENGINE DRESSED SNOW KING
PLATFORMS
*** LO DESIGNATOR IS USED FOR SUMMER SPEC ENGINES WITH WINTER SELF
TAPPING MOUNT CYLINDERS
▼ ▼
