LD MAUI 28 - REAR PANEL CONNECTIONS AND CONTROLS; AUDIO INPUTS AND OUTPUTS; POWER SWITCH AND CONNECTION

8
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS
ESPAÑOLPOLSKIITALIANO
CONTROL ELEMENTS:
1
INPUT RCA (LEFT / RIGHT)
2
INPUT XLR / PHONE JACK COMBO (LEFT /
RIGHT)
Balanced line input
3
OUTPUT XLR (LEFT / RIGHT)
Balanced line output
4
POWER SWITCH
On / off switch. Turn on connected devices such as
mixers, etc., before turning on the active system and
turn them off after turning off the active system.
5
POWER CONNECTION SEAT
240 V connector socket (IEC plug) and fuse hol-
der. The power connector must be disconnected
whenever the fuse is replaced. If the fuse burns
out repeatedly, the unit must be inspected by a
specialist.
3
2
45
1
