EN-134
CHANGING DOOR OPENING SIDE
This appliance has reversible doors but is delivered with a right hinged door. The left hand hinge kit
comes with the unit (in the box), should you wish to reverse the hinge on your unit.
For your safety, please unplug
appliance before doing this operation.
WARNING : Use extreme caution with the articulated hinges. The
hinge is self-closing and many pinch points exist prior to built-in
installation.
LM78, LMN78, LB160 and LBN160
1. Remove the bottom hi
nge (1) by unscrewing the four lock screws (2). Be careful to hold the glass
door firmly after removing the screws. (Fig. 1)
2. Gently pull down to remove the glass door from the right top hinge and place it on a padded surface
to avoid the risk of damage. Then remove the right top hinge (4). (Fig. 3)
3. Unscrew and transfer the hinge pin (3) of the bottom hinge to the opposite side. (Fig. 2)
4. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes on the right
hand side.
5. Screw the alternative left top hinge (6), included in the fittings, on the left hand side of cabinet. (Fig. 3)
6. Rotate the door 180° and relocate the door to the designated position. Then screw the bottom hinge
assembly on the left designated position and tighten it after the door is leveled.
LB340 and LBN340
