POWER CONSUMPTION | ThermalCharacteristics CONTINUED
Connect
Series
168
Connect
Series
88
Output Power
AC Power Consumption Amps Watts Amps
Watts Amps
Watts
Amps Watts
Amps Watts
1/4 Power Output 3.69 249 3.88
261
2.30 155
3.73
252 3.66
247
1/8 Power Output 2.14 145 2.23
151
1.44 97
2.16 146 2.11 142
idle
1.08 73 1.08
73 1.08
73 1.08
73
1.08 73
Auto Standby (all channels) 0.23 7 0.23 7 0.23 7 0.23 7 0.23 7
Heat Power
BTU/Hr Watts BTU/Hr
Watts
BTU/Hr Watts
BTU/Hr
Watts BTU/Hr
Watts
BTU/Hr & Watts 1/4 Power 304 89 346
101
255 75
312 92 297 87
BTU/Hr & Watts 1/8 Power 220 65 241 71 196 57 224 66 213 62
120VAC
8 ohm
4 ohm
2 ohm
70V
100V
8 x 80W
8 x 80W
8 x 80W
8 x 80W
8 x 80W
Output Power
AC Power Consumption Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts
1/4 Power Output 2.55 244 2.67 256 1.58 152 2.57 247 2.52 242
1/8 Power Output 1.48 142 1.54 148 1.00 96 1.49 143 1.46 140
idle 1.22 73 1.22 73 1.22 73 1.22 73 1.22 73
Auto Standby (all channels) 0.19 7 0.19 7 0.19 7 0.19 7 0.19 7
Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts
BTU/Hr & Watts 1/4 Power 288 84 329 96 246 72 296 87 280 82
BTU/Hr & Watts 1/8 Power 212 62 233 68 191 56 216 63 205 60
240VAC
8 ohm
4 ohm
2 ohm
70V
100V
8 x 80W
8 x 80W
8 x 80W
8 x 80W
8 x 80W
Output Power
AC Power Consumption Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts
1/4 Power Output 6.80 458 7.16 483 4.00 270 6.87 463 6.73 454
1/8 Power Output 3.69 249 3.80 256 2.26 152 3.66 247 3.56 240
idle 1.08 73 1.08 73 1.08 73 1.08 73 1.08 73
Auto Standby (all channels) 0.23 7 0.23 7 0.23 7 0.23 7 0.23 7
Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts
BTU/Hr & Watts 1/4 Power 472 138 556 163 374 110 488 143 457 134
BTU/Hr & Watts 1/8 Power 304 89 329 96 246 72 296 87 273 80
120VAC
8 ohm
4 ohm
2 ohm
8 x 160W
8 x 160W
8 x 160W
8 x 160W
8 x 160W
70V
100V
Output Power
AC Power Consumption Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts
1/4 Power Output 4.67 449 4.92 473 2.75 264 4.72 453 4.63 444
1/8 Power Output 2.55 244 2.67 256 1.58 152 2.57 247 2.50 240
idle 1.22 73 1.22 73 1.22 73 1.22 73 1.22 73
Auto Standby (all channels) 0.19 7 0.19 7 0.19 7 0.19 7 0.19 7
Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts
BTU/Hr & Watts 1/4 Power 439 129 521 153 356 104 455 133 424 124
BTU/Hr & Watts 1/8 Power 288 84 329 96 246 72 296 87 273 80
240VAC
70V
100V
8 x 160W
8 x 160W
8 x 160W
8 x 160W
8 x 160W
8 ohm
4 ohm
2 ohm
