SPECIFICATIONS | ProductData
Output
Power
(20Hz to 20kHz)
Connect Series 88
8 x 80 WRMS @ 4Ω, 8Ω, 70V, 100V (40W at 2Ω, 80W at 25V)
Connect Series 168
8 x 160 WRMS @ 4Ω, 8Ω, 70V, 100V (80W at 2Ω, 160W at 25V)
Connect Series 84
4 x 80 WRMS @ 4Ω, 8Ω, 70V, 100V (40W at 2Ω, 80W at 25V)
Connect Series 164
4 x 160 WRMS @ 4Ω, 8Ω, 70V, 100V (80W at 2Ω, 160W at 25V)
Connect Series 354
4 x 350 WRMS @ 4Ω, 8Ω, 70V, 100V (175W at 2Ω, 230W at 25V)
Connect Series 704
4 x 700 WRMS @ 4Ω, 8Ω, 70V, 100V (350W at 2Ω, 330W at 25V)
Connect Series 352
2 x 350 WRMS @ 4Ω, 8Ω, 70V, 100V (175W at 2Ω, 230W at 25V)
Connect Series 702
2 x 700 WRMS @ 4Ω, 8Ω, 70V, 100V (350W at 2Ω, 330W at 25V)
Audio Spec
Inputs
Analog: Balanced Inputs with user selectable 26 dB and 34 dB input sensitivity (2CH = 2 inputs, 4CH=4
inputs, 8CH = 8 inputs)
THD+N
0.1% (20Hz to 20kHz)
Frequency
Response
+/- 0.5 dB @ 4Ω, 8Ω, 70V, 100V, -2.5dB @ 20kHz at 2Ω
Signal to Noise
Level
105dB (20Hz to 20kHz referenced to 8Ω)
Crosstalk
70dB (20Hz to 20kHz)
I/O Latency
1 ms DSP latency under any condition
Load Impedance
LowZ down to 2 ohms, 70V direct, and 100V Direct per channel
Amplifier Output
Classification
Class D with Proprietary Smart Power Bridge Technology allowing bridged output functionality without
sacrificing an amplifier channel
DC Offset
+/- 3mV
DSP
DSP Architecture
Analog Devices Sigma 96kHz DSP Processor with 32-bit Core with Sample Rate Converters
Input Matrix
Routable matrix; any input to any output with primary and secondary input priority
Crossovers
Up to 48 dB/Octave IIR Filters (Linkwitz Riley, Butterworth)
Parametric EQ
8 Band Parametric EQ per channel
Output Delay
100ms per channel
Output Protection
DC, VHF, and AC Mains Protection, Overtemp and Current Limiter, fan fault detection
User Adjustable
Limiting
Peak Voltage and RMS Voltage
Load Monitoring
Realtime Load Monitoring and Pilot Tone Detection from Internal or External Sources
Control,
Monitoring,
Network
Network
Connectivity
WiFi or 100MB Ethernet with PoE or Built in WiFi Access Point (IEEE 802.11
2.4GHz b/g/n WPA, WAP2, WEP)
User Interface
Web Browser User Interface, 3rd Party API control, or CLOUD control
Supported
Operating Systems
MAC, iOS, PC, Android
Event Reporting
User Downloadable and Viewable Event and Fault log - POE allows for enhanced error
monitoring
External I/O
External I/O In: Toggles Remote On/Off
External I/O Out: Indicates
Amplifier Health
Cloud IoT
Cloud based IoT functionality
Operation
AC Mains
100VAC - 240VAC +/- 10% 50Hz or 60Hz
Temperature
Storage: -20°C to 90° C - Operating: 0°C to 55° C
Power Supply
Universal Switch Mode Power Supply with Power Factor Correction (No PFC in Connect
S
eries
84
,
C
onnect
S
eries
164
,
C
onnect
S
eries
88, &
C
onnect
S
eries
168
)
Safety Approvals
UL, CSA,CE, ETL, FCC, CCC, KETI, NOM , ROHS, PSE
Physical
Spec
Dimensions (L x W
x H)
Product: 14.25” x 19” x 1U (362mm x 482mm x 1U
Shipping: 20” x 22.75” x 3.75” (508mm x 578mm x 95.25mm)
Weight
Connect Series 352 & Connect Series 702: 10lbs / 3.4kg | Shipping: 17.4lbs / 7.9kg
Connect Series 354 & Connect Series 704: 14lbs / 4kg | Shipping: 18.7lbs / 8.5kg
Connect Series 84 & Connect Series 164: 12.05lbs / 5.46kg | Shipping: 16.35lbs / 7.41kg
Connect Series 88 & Connect Series 168: 13.35lbs / 6.05kg | Shipping: 17.75lbs / 8.05kg
Cooling
Front to Rear Variable Fan Speed Cooling
Fan Noise at idle is 50dB @ 1m
Fan Noise at 50% is 57dB @ 1m
Fan Noise
at full speed
is
63
dB @ 1m
Connectors
Analog Input: 3 pin Amphenol Anytek, Output: 2 pin Amphenol Anytek, External IO: 3 pin Amphenol Anytek,
Power in: IEC, Ethernet RJ45 In for Control ***Note: Connect Series 84, Connect Series 164, Connect
S
eries
88, &
C
onnect
S
eries
168
do not have potentiometers on the rear panel
The Connect Series’ WiFi connectivity is achieved using the Japanese certified wireless module ATWILC1000
-
MR110UB.
