9 Installation
Connecting the Battery
To connect the battery, perform the following steps:
1. Disconnect the battery from the vehicle power circuit.
Warning: Disconnect the negative cable first.
2. Secure the positive cable of the device as close as possible to the battery
with a suitable fuse.
Model
ABC 12100
ABC 1260, ABC 2440,
ABC 2450, ABC 2460
ABC 3640
ABC 4830
Fuse
125 A
75 A
50 A
40 A
Cross
section
25 mm
2
10 mm
2
6 mm
2
6 mm
2
3. Connect the positive cable of the device to the positive terminal of the
battery.
4. Connect the negative cable of the device to the negative terminal of the
battery.
5. Connect the vehicle battery to the vehicle power circuit again.
The battery is connected.
Connect the Device to the 230-V Mains
To install the device to the 230-V mains, perform the following step:
1. Connect the mains plug to a 230-V mains supply.
 The charger is only suitable for connection to fused, earthed
230 V mains supplies.
 The device switches on as soon as a voltage of 230 V is
connected.
The charger is connected to the 230-V mains supply.
