LEAB 12100 - Technical Specifications

Installation Instructions Technical Specifications
Page 4 of 14
5 Technical Specifications
Model
ABC 12100
ABC 12100
ABC 1260
Part number
0101036178
0101036179
0101036170
Battery
Battery type
Lead acid (wet, gel, AGM)
Charging characteristics
15 optional characteristics (see characteristics
sheet)
rec. battery capacity
200 Ah…
1000 Ah
200 Ah…
1000 Ah
150 Ah…
600 Ah
Charging current
Charging current, max.
100 A
60 A
Charging current, duration
100 A
60 A
Ripple
< 3%
Charge voltage
Main charging
14.2 V / 14.4 V
Trickle charging
13.6 V / 13.8 V
Supply voltage (AC)
Input voltage (rated values)
230 V / 50 Hz / 8 A
Input voltage
90 V… 270 V
(< 200 V reduced charging current)
Input frequency
0 Hz … 400 Hz
Quiescent current (out of the
battery)
< 2 mA
Switching frequency
100 kHz
recommended mains fuse
B16 A or C16 A
Degree of efficiency, max.
> 88 %
Protection class
I
Operating temperature
-30 °C … +60 °C
IP rating
IP21
Dimension, housing
(L x W x H)
265 mm x 135 mm x 85 mm
Weight (without cable)
2.6 kg
Connections
AC cable
1.5 m, 1 mm²
1.5 m, 1 mm²
1.5 m, 1 mm²
Mains plug
Two-pin
earthed plug
Two-pin
earthed plug
Two-pin
earthed plug
DC cable
2 x 1.5 m,
25 mm²
2 x 1.5 m,
25 mm²
2 x 2 m,
10 mm²
CBL
no
yes
no
CTS/TS
yes
yes
yes
