LEAB 12100 - Charging Characteristics

Installation Instructions Charging Characteristics
Page 8 of 14
Model
ABC 4830
ABC 4830
Part number
0101036437
0101036430
Dimension, housing (L x W x H)
265 mm x 135 mm x 85 mm
Weight (without cable)
2.6 kg
Connections
AC cable
1.5 m, 1 mm²
1.5 m, 1 mm²
Mains plug
Two-pin earthed plug
Two-pin earthed plug
DC cable
2 x 2 m, 10 mm²
2 x 2 m, 25 mm²
CBL
yes
no
CTS/TS
no
yes
Remote display
yes
yes
On/off switch
no
no
6 Charging Characteristics
The ABC charger contains 15 different charging characteristics which you can
select before connecting to the battery. Battery charging is fully automatic
and micro-processor controlled with a 3-stage IU
1
U
2
characteristic curve for
gentle and optimum charging of the batteries.
The available charging characteristics can be found on the characteristics
sheet.
I U
1
U
2
