LEAB 12100 - Page 6

Installation Instructions Technical Specifications
Page 5 of 14
Model
ABC 12100
ABC 12100
ABC 1260
Part number
0101036178
0101036179
0101036170
Remote display
yes
no
yes
On/off switch
no
no
no
Model
ABC 2440
ABC 2450
ABC 2460
Part number
0101036040
0101036050
0101036060
Battery
Battery type
Lead acid (wet, gel, AGM)
Charging characteristics
15 optional characteristics (see characteristics
sheet)
rec. battery capacity
120 Ah …
400 Ah
140 Ah …
500 Ah
150 Ah …
600 Ah
Charging current
Charging current, max.
40 A
50 A
60 A
Charging current, duration
40 A
50 A
60 A
Ripple
< 3%
Charge voltage
Main charging
28.4 V / 28.8 V
Trickle charging
27.2 V / 27.6 V
Supply voltage (AC)
Input voltage (rated values)
230 V / 50 Hz / 8 A
Input voltage
90 V… 270 V
(< 200 V reduced charging current)
Input frequency
0 Hz … 400 Hz
Quiescent current (out of the
battery)
< 2 mA
Switching frequency
100 kHz
recommended mains fuse
B16 A or C16 A
Degree of efficiency, max.
> 88 %
Protection class
I
Operating temperature
-30 °C … +60 °C
IP rating
IP21
Dimension, housing (L x W x H)
265 mm x 135 mm x 85 mm
Weight (without cable)
2.6 kg
Connections
AC cable
1.5 m, 1 mm²
1.5 m, 1 mm²
1.5 m, 1 mm²
Mains plug
Two-pin
earthed plug
Two-pin
earthed plug
Two-pin
earthed plug
