Installation Instructions About the CDR
Page 4 of 6
5 About the CDR
6 Mounting
To mount the device, perform the following steps:
 Do not mount the device directly next to or above batteries.
 To allow adequate cooling, ensure an unimpeded supply of
cooling air.
Fasten the device to the 4 lateral holes (6 mm Ø).
7 Installation
To install the CDR, perform the following steps:
No.
Part Name
1
Screw terminal 1 / Input
2
Screw terminal 2 / Output
3
Connection cable LED (grey)
Connection cable GND (black)
Connection cable bypass button (blue)
The device is mounted.
In vehicles with generator management, additional batteries are
not sufficiently charged by conventional cut-off relays or current
distributors.
We recommend the LEAB charge booster (part number):
1041003001).



