Model
LPS-162A
LPS-163A
LPS-164A
Output voltage
0- 32V continuously variable
Output polarity
Positive and negative
Output current
0-2A o-3A
0-5A
Ripple voltage
Less than 3 mVp-p
Output stability
Less than 5mV for power source voltage change
of± 10%
Less than 5mV for load variation of 0 to 100%
Voltmeter 40V (F.S)
Accuracy of 2.5% for full scale
Amperemeter
2.5A (F.S) 4A (F.S)
6A (F.S)
Accuracy of
Accuracy of
Accuracy of
2.5% for fuil
2.5% for full
2.5% for full
scale
scale scale
Insulation
Between chassis and output terminal:
More than 1 0 MD at DC 500V
Between chassis and AC plug:
More than 50M.Q at DC 500V
Compensation/
. Overload protection circuit of constant current
protection
circuit
self-restoring type
Ambient temper:
0
-± 40°C
ature range
Power source
AC100-120V AC100- 120V AC100- 120V
50/60Hz 153V A
50/60Hz
220V A 50/60Hz 340V A
AC200~ 240V
AC200- 240V
AC200~ 240V
50/60Hz 77VA 50/60Hz 11 OVA 50/60Hz 170V A
· Size and weight
175(H)x115(W)
175(H)x150(W)
175(H)x150(W)
x225(D)mm
300(D)mm
300(D)mm
7kg
8
kg
8.8 kg
Accessories
Short-circuit bar x 1
Fuse
X 1
Operation
Series and parallel
