Leader Electronics Corp. LSG-17 - Description; Front Panel Controls Overview

Audio Output
Cyrstal Oscillator
Power Supply
Size and Weight
1kHz; 1 Vrms or more (fixed).
For l-l5 MHz crystal in Type FT-243
holder. (not included).
100, 115
120, 220 - 240V, 50/60Hz;
approx.3VA.
l50(H)
X 238(W) X80(D) mm; 2.5kg.
SECTION 2
DESCRIPTION
®
2.1 Controls
Frequency dial Sets the RF output frequency in
the range selected with FREQ
RANGE switch.
FREQ RANGE switch With six positions for RF output
frequency range.
- 2 -
