LeapFrog ClickStart User Manual

AC Adapter Electrical Ratings:
US, CAN Input: ~120VAC, 60Hz
UK Input: ~230V, 50Hz
Australia and New Zealand Input: ~240V, 50Hz
Output:
DC5V, 500mA, 2.5VA
Important Note for the CLICKSTART™ Console
The unit may malfunction when radio interference appears on the power line.
The unit will revert to normal operation when the interference stops.
Note: In the unlikely event of an electrostatic discharge, the unit may
malfunction and lose memory, requiring the user to reset the device.
Consignes de sécurité pour l’utilisation de l’adaptateur
(Adaptateur vendu séparément ; produit LeapFrog Enterprises, Inc.)
Le cordon de l’adaptateur peut provoquer un
risque d’étranglement.
Ne convient pas aux
enfants de moins de
3 ans. Comme tous les
objets utilisant du
courant électrique, ce produit doit être manipulé avec précaution pour éviter tout risque
de décharge électrique.
AVERTISSEMENT :
ATTENTION : CE JOUET
FONCTIONNE À L’ÉLECTRICITÉ
11
TROUBLESHOOTING
Product does not turn on
or does not respond
Product makes strange sounds
or behaves erratically
• Make sure console power light is on
• Touch any key on the keyboard
• Make sure there is a line-of-sight between the console and the keyboard
• Make sure batteries are correctly installed
• Make sure battery cover is securely attached
• Insert the end of a paper clip into the RESET pinhole on the bottom of the console or on the bottom of the keyboard
• Remove and reinsert cartridge, making sure the cartridge is inserted all the way into the slot
• Remove batteries and put them back in
• Clean battery contacts by rubbing lightly with a soft eraser and then wiping with a clean and dry cloth
• Install new batteries
• Follow the above instructions to clean battery contacts
• Install new batteries
Symptom:
Try This:
Product makes improper responses
• Follow the above instructions to clean battery contacts
• Install new batteries
Display stops working
• Adjust brightness/contrast controls on the TV
• Install new batteries
• Make sure TV is on
• Make sure cables are fully inserted
Power light not on
• Press the On button on the console
• Make sure batteries are correctly installed
• Install new batteries
Power light on but no picture on TV
• Make sure the yellow video connector is fully inserted in the correct input jack on the TV
• Make sure the SCART connector or Euro-connector is correctly inserted in the SCART input on the TV
• Make sure that the correct colored/coloured cable on the unit is plugged into the matching video (yellow) input jack on the SCART
connector
• Make sure you have selected the correct video input on your TV
Power light on but no sound from TV
• Make sure the white audio connector is fully inserted in the correct input jack
• Make sure the SCART connector or Euro-connector is correctly inserted in the SCART input on the TV
• Make sure that the correct colored/coloured cable on the unit is plugged into the matching video (yellow) input jack on the SCART
connector
• Adjust the volume settings on the TV
Colors/Colours are distorted on TV
or TV image is flickering
Images on the TV appear stretched
or cut off at the top and bottom
• Make sure the TV is set to display the standard 4:3 aspect ratio
• Make sure the yellow video connector is fully inserted in the correct input jack on the TV
• Make sure you have selected the correct video input on your TV
• Make sure the PAL/NTSC switch is in the correct position; the switch is located in the console’s battery compartment. Turn the console
off and back on again after switching between PAL and NTSC.
• Use NTSC for most U.S. TV sets; use PAL for most TV sets in Europe and the U.K. For some TV sets in the U.S., if the screen still
flickers, try switching to PAL. Turn the console off and back on again after switching between NTSC and PAL.
À UTILISER UNIQUEMENT EN INTÉRIEUR, DANS UN ENDROIT SEC.
Le transformateur n’est pas un jouet et il est recommandé que ce soit un
adulte qui le branche à la prise murale. Pour éviter tout danger d’incendie,
d’électrocution ou de blessure, veillez à contrôler périodiquement l’état du
cordon électrique, de la fiche d’alimentation électrique, des lames de contact,
du boîtier ou de toute autre partie. Dans un tel cas, le transformateur doit être
réparé avant d’être réutilisé.
Le jouet doit seulement être utiliser avec l’adaptateur recommandé.
Le jouet ne doit pas être branché à plus d’accessoires que le nombre
recommandé.
Débrancher le jouet de l’adaptateur avant de le nettoyer avec du liquide.
Pour nettoyer l’adaptateur, débranchez-le d’abord de la prise murale et utilisez
ensuite un tissu humide pour le nettoyer.
Voltage de l’adaptateur
Voltage d’entrée pour les Etats-Unis et le Canada : ~120V, 60Hz
Voltage d’entrée pour le Royaume Uni : ~230V, 50Hz
Voltage d’entrée pour l’Australie et la Nouvelle Zélande : ~240V, 50Hz
Voltage de sortie :
DC5V, 500 mA, 2.5VA
Colors/Colours do not appear accurate
• Make sure the cartridge is inserted in the correct direction, with the label facing front
• Make sure the cartridge is inserted all the way into the cartridge slot
• Make sure there is no foreign material in the cartridge slot
Cannot get cartridge game to play
• Touch any button on the keyboard
• Make sure there are no items blocking the IR receiver on the console from receiving a signal from the keyboard
Game does not respond to keyboard
• Touch any key on the keyboard
• Make sure the mouse is plugged into the keyboard correctly
Mouse not functioning
• Adjust the color/colour settings on the TV
Power light does not turn on or off
• Hold the On/Off button down for a few seconds, until the power light turns on/off.
