LeapFrog LF2936FHD - Product Overview; Parent Unit Components; Baby Unit Components

6
Baby Unit
1 Light sensor
2 Camera
3 Infrared LEDs
4 Microphone
5 Night light
6
Night light control key
• Press to turn the night light on or off.
• Press and hold to adjust night light
brightness level.
7 Speaker
8 POWER LED Light
9 On / Off switch
10 Antenna
11 Power jack
12 Wall mount holes
13 PAIR key
• The Parent Unit and Baby Unit(s)
provided are already paired.
7
8
6
9
4
3
5
2
1
12
13
10
11
7
8
6
9
4
3
5
2
1
12
13
10
11
7
8
6
9
4
3
5
2
1
12
13
10
11
Overview
1 3-level sound indicator
2
Power /
LCD Off
3 Microphone
4
/ / /
/Arrow keys
•
or to adjust volume.
•
or to adjust screen
brightness.
• Navigate within the menus.
• Pan and tilt the camera.
5
Menu / Select
6
Talk
/
Return
2
1
4
5
6
7
8
3
10
11
9
12
Parent Unit
7
Battery LED indicator
8
Link LED indicator
9 Antenna
10 Power jack
11
RESET
12 Stand
