p.22 Squiggles
+
Stander User Manual
9.17 Adjusting the
height of the tray in
prone and supine
The height adjustment
knobs for the tray are
located on either side of
the central spine. Loosen
the 2 knobs
, select
the required height
and re-tighten.
9.18 Adjusting the depth
and angle of the tray
Loosen the adjustment knob
on either side, slide the
tubes along the receiving
brackets to achieve the
desired depth and re-tighten
the knobs. To adjust the
angle of the tray loosen the
knobs
on either side of
the tray, set the tray to the
required angle and
re-tighten securely.
Never use the tray to
steer or push the chair.
Do not place hot objects
on the tray, greater than
40 degrees Celsius.
Please note that the
tray is for the use of the
user only. Do not lean or
place heavy objects on
the tray greater than
8kgs (17.6lbs)
