Stander User Manual p.31
16.0 Technical Information
Product and Accessory Codes
184-600 Stander support
184-764 Pivot Chassis
184-1800-02 Stander covers – Blue
184-1800-04 Stander covers – Purple
184-1800-09 Stander covers – Red
184-1800-09VIN Stander covers – Red Vinyl
Accessories
Codes prexed by an asterix are available in four colour options.
02 – Blue
04 – Purple
09 – Red
09VIN – Red Vinyl
152-1600 Size 1 Sandals
152-2600 Size 2 Sandals
118-619 Tray
117-769 Grab Rails
118-697 Headrest Support
*184-1814 Headrest cushion with laterals
118-687 Headrest laterals
Age (approx.) 1-5
Max User Weight 22kg / 48.4lbs
User Height - Min 730mm / 28.5 inches Max 1100mm / 43.3 inches
Chest Support Height (Distance from footplate to armpit)
Min 160mm / 6.25 inches
Max 820mm / 32 inches
Chest / Hip Width - Min 160mm / 6.25 inches Max 230mm / 9 inches
Hip Support Height (Distance from footplate to mid-buttock)
Min 300mm / 11.8 inches
Max 530mm / 20.8 inches
Distance between mid line of knees - Min 140mm / 5.5 inches Max 215mm / 8.4 inches
Footplate - Plantarexion 10
0
Dorsiexion 10
0
Pivot chassis angle range - 90-180º Pivot chassis angle range 90 - 70º
Tray height - prone - Min 555mm / 21.9 inches Max 825mm / 32.5 inches
Tray height - supine - Min 480mm / 18.5 inches Max 825mm / 32.5 inches
Pivot chassis footprint (Minimum dimensions for storage)
Min 5.5kg / 12.1lbs
Width 550mm / 21.7 inches
Length 700mm / 27.6 inches
Height 300mm / 11.8 inches
Standard support frame
(Minimum dimensions for storage)
Min 7kg / 15.4lbs
Width 380mm / 15.4 inches
Length 890mm / 26.8 inches
Height 380mm / 15.4 inches
