Lectrosonics IFBT4 - Accessories

Multi-Frequency IFB Transmitter
Rio Rancho, NM
11
SNA600
Accessories
CH20
Power supply for IFB base transmitters with locking
LZR power jacks; 110 VAC input, 12 VDC regulated
output; 400 mA max.
SNA600
Collapsible dipole antenna that adjusts over a wide
frequency range. Ideal for situations where a full
360 degree receiving pattern is required as op-
posed to a directional pattern.
ALP Series Antennas
ALP500, ALP620 & ALP650 Shark Fin style Log
Periodic Dipole Array (LPDA) Antennas that provide
a useful directional pattern over a broad frequency
bandwidth. Ideal for portable applications including
temporary setups for field production.
ALPKIT
Stainless steel kit for mounting SNA600 and ALP
Series antennas on photo and video tripods, light-
ing equipment, and standard microphone stands.
ARG15
A 15 foot antenna cable of standard RG-58 coax
cable with BNC connectors at each end. Loss of 1
to 2 dB with 0.25” diameter.
ARG25/ARG50/ARG100
An antenna cable of Belden 9913F low-loss coax
cable with BNC connectors at each end. Double
shielded, flexible, 50 Ohms, with a foamed poly-
ethylene dielectric. Lower loss (1.6 to 2.3 dB) with
somewhat less weight than standard RG-8 with the
same 0.400” diameter. Available in 25, 50 and 100
foot lengths.
RMP195
4 channel rack mount for up to four IFBT4
transmitters. Rocker switch included to work as a
master power switch if desired.
21425
6 ft. long power cord; coaxial to stripped & tinned
leads. Coaxial plug: ID-.080”; OD-.218”; Depth- .5”.
Fits all compact receiver models that use CH12
power supply.
21472
6 ft. long power cord; coaxial to stripped & tinned
leads. Right angle coaxial plug: ID-.075”; OD-.218”;
Depth- .375”. Fits all compact receiver models that
use CH12 power supply.
21586
DC16A Pigtail power cable, LZR stripped & tinned.
CH20
ARG15
ARG25
ARG50
RMP195
.475”
.375” O.D.
.375”
.35”
.375” O.D.
.475” O.D.
Locking collar with
5/16”-32 thread
21425
21472
21586
