4
General Safety Information
Thank you for your purchase from the Leer team.
Read this manual and retain it for future reference. If you
sell your merchandiser, please leave this manual with the
merchandiser for the next owner.
Properly handle refrigerants according to local and national
regulations before you scrap your old merchandiser.
Risk of child entrapment. Do not allow a child to play
around or in a merchandiser! Help save a child’s life. While
in use or before you store your old freezer, ensure the doors
are locked, mechanically blocked open or chained shut to
prevent entrapment. Before you recycle your old freezer,
take off the doors and remove the drain plug in the bottom
of the cabinet.
Do not store or use gasoline or any other flammable
material in the vicinity or inside any Leer product. Follow
any local codes that may apply.
Storage and Transportation:
The merchandiser shall be stored and transported in an
upright position. It is not recommended to tilt the
merchandiser. If the merchandiser is tilted beyond 45° of
vertical, oil may drain from the compressor causing
premature failure.
Do Not stack merchandisers on top of one another due to
risk of falling. Falling merchandisers could result in
damaged units or serious injuries. It is recommended to use
a warehouse racking design to accommodate the weight of
the merchandisers and prevent falling.
Unpacking and Pallet Removal
Prior to installation, the outer packaging on the Vending
Machine will need to be removed. The majority of the
packaging materials can be recycled and disposed of in an
environmentally friendly manner. The wooden skid is
secured to the Vending Machine with hex-headed screws
and will require the use of a 3/8" (10mm) hex-socket for
screw removal.
1. First remove two screws from each side perimeter
board using a long 3/8” (10mm) hex-socket.
2. Remove the Philips screws from the front
perimeter board and remove the board.
3. Remove the Philips screws from the left or right
side. This will remove the skid footing to aid in use
of pallet jack.
4. Insert forks on lifting device from the front side.
CAUTION: Stay clear of the load cells.
5. Use lifting device to lift the unit high enough to
remove pallet and the orange pallet cushions from
the back.
6. Slide unit off the pallet jack into position on a
sturdy level surface. Use the included stackers for
leveling if required.
Set-Up
Set-up Prior to Installing at Retail Location:
The Vending Machine refrigeration system will arrive at the
customer location ready to operate within design parameters
that have been tested and deemed optimum for ice storage.
