23
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P170
Slip
Compensation
0.0 0.0 {%} 10.0 Increase P170 until the motor speed no
longer changes between no load and
full load conditions.
p171
(1)
Current Limit 200 30 {%} CLim
max
• When the limit is reached, the
drive displays CL, and either the
acceleration time increases or the
output frequency decreases.
• Digital outputs can also indicate
when the limit is reached; see P140,
P142.
• Refer to section 2.2 for CLim
max
P174
DC Brake
Voltage
0.0 0.0 {%} 30.0 Setting is a percent of the nominal DC
bus voltage.
p175
DC Brake Time 0.0 0.0 {s} 999.9
Note
CONFIRM MOTOR SUITABILITY FOR USE WITH DC BRAKING
DC Brake voltage (P174) is applied for the time specified by P175 with the
following exceptions:
• If P111=1, 3 and P175=999.9 the brake voltage will be applied
continuously until a run or fault condition occurs.
• If P110=2, 4…6 and P175=999.9, brake voltage will be applied for 15s
• If P121…P123=18 and the corresponding TB-13 input is CLOSED,
brake voltage will be applied until the TB-13 input is OPENED or a fault
condition occurs.
p178
Display
Frequency
Multiplier
0.00 0.00 650.00 • Allows frequency display to be
scaled
• P178 = 0.00: Scaling disabled
• P178 > 0.00: Display = Actual
Frequency X P178
Example: If P178 = 29.17 and actual frequency = 60 Hz,
Drive displays 1750 (rpm)
p179
Run Screen
Display
0 0 {Parameter Number} 599 • 0 = Normal Run Screen, this display
depends on mode of operation.
See Section 4.2.
• Other selections choose a diagnostic
parameter to display (P501…P599).
p181
Skip frequency 1 0.0 0.0 {Hz} 500 • Drive will not run in the defined skip
range; used to skip over frequencies
that cause mechanical vibration
• P181 and P182 define the start of
the skip ranges
• P184 > 0 defines the bandwidth of
both ranges.
p182
Skip frequency 2 0.0 0.0 {Hz} 500
p184
Skip frequency
bandwidth
0.0 0.0 {Hz} 10.0
Note
Bandwidth (Hz) = f
s
(Hz) + P184 (Hz) f
s
= P181 or P182
Example: P181 = 18 Hz and P184 = 4 Hz; skip range is from 18 to 22 Hz
(1) Any changes to this parameter will not take effect until the drive is stopped
