What to do if my Leeson Inverter shows 'PWR SAG'?
If the Leeson Inverter displays 'PWR SAG' due to an erratic AC line, perform a factory reset using Parameter 65-PROGRAM. This action updates the software and allows the fault to be reset.
Why is my Leeson 174475 Inverter display blank and the drive won't run?
If the Leeson Inverter displays a blank screen and will not run, it indicates the power supply has shut down. Inspect the heatsink fans for obstructions. If the fans are clear and the issue persists, contact the AC Tech Service Department.
Why does my Leeson 174475 Inverter show an OVERLOAD error?
The Leeson Inverter might be showing an OVERLOAD error because the drive is undersized for the application, or there might be a problem with the motor or the driven equipment.
Why does my Leeson 174475 Inverter show 'HI VOLTS'?
If the Leeson Inverter displays a 'HI VOLTS' error, it could be due to high line voltage, an overhauling load, or the deceleration rate being set too fast.
What causes 'HI TEMP' error on Leeson 174475?
If the Leeson Inverter displays a 'HI TEMP' error, it could be due to a high ambient temperature or a fan failure (if equipped).
What to do if Leeson 174475 shows 'CONTROL'?
If the Leeson Inverter displays 'CONTROL', perform a factory reset using Parameter 65-PROGRAM. This action updates the software and allows the fault to be reset.
Why does my Leeson Inverter display 'LO VOLTS'?
If the Leeson Inverter displays 'LO VOLTS', it is due to low line voltage.
What causes 'OUTPUT' error on Leeson Inverter?
The 'OUTPUT' error on a Leeson Inverter can be caused by a phase to ground short, a phase to phase short, the FX or AC BOOST being set too high, or a bad transistor module (IPM).
General| Phase | 3 |
|---|---|
| Enclosure | TEFC |
| Speed | 1750 |
| Service Factor | 1.15 |
| Ambient Temperature | 40°C |
| Altitude | 3300 ft |
| Frequency | 60 Hz |
LEESON Electric reserves the right to modify products without prior notice.
LEESON Electric warrants products for 12 months from sale or 24 months from manufacture.
Inspect cartons for damage and shortages upon receipt.
LEESON Electric cannot assume responsibility for unauthorized modifications.
Presents physical dimensions for Type 1 enclosed models.
Provides dimensions for Washguard NEMA 4/12, 12, and 4X enclosures.
Explains the basic principles of AC motor operation and synchronous speed.
Compares constant torque and variable torque loads and their characteristics.
Overview of the drive's components and functionality.
Describes how the drive converts AC input to variable AC output.
Details the control board, power board, and protection circuits.
Lists analog and digital inputs/outputs and their functions.
Drives must not be installed in adverse environmental conditions.
Procedure for reforming DC bus capacitors after storage.
Details voltage, phase, and imbalance requirements for input power.
Specifies requirements for circuit breakers and fuses.
Lists input voltage ratings and operating ranges for MICRO Series drives.
Instructions for wiring single-phase and three-phase power inputs.
Explains the functions of the keypad buttons for operation.
Describes the drive's display configurations in different modes.
Details the display readouts when the drive is in STOP mode.
Details the display readouts when the drive is in RUN mode.
Explains the display behavior when the drive encounters a fault.
Describes the auxiliary status screen display.
General guidelines for control wiring practices.
How the drive can be controlled via the keypad.
Best practices for separating control and power wiring.
Function and connection of TB-2 circuit common terminal.
Methods for suppressing surges from relays and solenoids.
How to select REMOTE mode for control.
Implementing two-wire start/stop control for forward rotation.
Alternative method for two-wire start/stop control.
Procedures for three-wire start/stop control.
Available analog speed reference inputs.
How to select speed references like AUTO/MAN vs. LOCAL/REMOTE.
Identifies terminals on the control board and their functions.
Wiring diagram for two-wire start/stop control with speed reference.
Wiring diagram for three-wire start/stop control.
Wiring for speed pot and preset speed control.
Guide to entering program mode and setting parameters.
How to quickly access and program parameters using Speed Dial.
Parameter for calibrating drive to input voltage.
Configures preset speed selections via terminal inputs.
Sets the acceleration time from 0 Hz to base frequency.
Sets the deceleration time from base frequency to 0 Hz.
Defines the lower limit of the drive's speed range.
Defines the upper limit of the drive's speed range.
Sets the DC voltage applied for motor braking.
Determines the duration of DC braking voltage application.
Enables the dynamic braking circuit for high-inertia loads.
Sets the maximum output current limit to control torque.
Protects the motor from overheating due to excessive current.
Selects the drive's output curve (constant or variable V/Hz).
Sets the carrier frequency for output IGBT switching.
Selects the drive's starting method (NORMAL, POWER-UP, etc.).
Selects the motor stop mode (COAST or RAMP).
Sets motor rotation direction (FORWARD, REVERSE, FWD&REV).
Selects speed control method in LOCAL mode.
Selects speed reference source for MANUAL control.
Selects source for start/stop and direction commands.
Sets the units for the output speed display.
Scales the output speed indication on the display.
Adjusts the decimal point location in the speed display.
Scales the load display and affects motor overload circuitry.
Adjusts the contrast of the drive's LCD display.
Sets the threshold for entering Sleep Mode.
Sets the delay time before entering Sleep Mode.
Sets minimum analog speed reference input frequency.
Sets maximum analog speed reference input frequency.
Filters analog input signals to reduce electrical noise.
Selects analog output signal type for TB-10A (frequency).
Scales the analog output signal at TB-10A.
Selects analog output signal type for TB-10B (load).
Scales the analog output signal at TB-10B.
Configures the function of terminal TB-13A for input.
Configures the function of terminal TB-13B for input.
Configures the function of terminal TB-13C for input.
Selects the operation of the EXTERNAL FAULT function for TB-13D.
Sets the open-collector output indication for terminal TB-14.
Sets the open-collector output indication for terminal TB-15.
Configures the auxiliary relay for status indication.
Activates serial communications for control and monitoring.
Sets the serial communication address for multi-drive networks.
Limits access to programmable parameters for security.
