43
17.0 PARAMETER MENU
PARAMETER MENU
PARAM. PARAMETER RANGE OF FACTORY
NUMBER NAME ADJUSTMENT DEFAULT
0 LINE VOLTS HIGH, LOW, AUTO AUTO
1 SPEED #1 MIN FRQ - MAX FRQ 20.00 Hz
2 SPEED #2 MIN FRQ - MAX FRQ 20.00 Hz
3 SPEED #3 MIN FRQ - MAX FRQ 20.00 Hz
4 SPEED #4 MIN FRQ - MAX FRQ 20.00 Hz
5 SKIP #1 .00 Hz - MAX FRQ .00 Hz
6 SKIP #2 .00 Hz - MAX FRQ .00 Hz
7 BAND WID .00 - 10.00 Hz 1.00 Hz
8 ACCEL NOTE 1 30.0 SEC
9 DECEL NOTE 1 30.0 SEC
10 MIN FRQ .00 - MAX FRQ .50 Hz
11 MAX FRQ MIN FRQ - 120.0 HZ (NOTE 2) 60.00 Hz
12 DC BRAKE NOTE 1 .0 VDC
13 DC TIME .0 - 999.9 SEC .0 SEC
14 DYN BRAKE OFF, ON OFF
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
NOTE 2: MAX LIMIT IS 650 Hz ON UNITS WITH HIGH FREQUENCY SOFTWARE.
