Leeson 174475 - USER SETTING RECORD

71
20.0 USER SETTING RECORD
PARAMETER MENU: USER SETTING RECORD
PARAM. PARAMETER FACTORY USER
NUMBER NAME DEFAULT SETTING
0 LINE VOLTS AUTO
1 SPEED #1 20.00 Hz
2 SPEED #2 20.00 Hz
3 SPEED #3 20.00 Hz
4 SPEED #4 20.00Hz
5 SKIP #1 .00 Hz
6 SKIP #2 .00 Hz
7 BAND WID 1.00 Hz
8 ACCEL 30.0 SEC
9 DECEL 30.0 SEC
10 MIN FRQ .50 Hz
11 MAX FRQ 60.00 Hz
12 DC BRAKE .0 VDC
13 DC TIME .0 SEC
14 DYN BRAKE OFF
16 CURRENT 180%
17 MOTOR OL 100%
18 BASE 60.00 Hz
19 FX BOOST (NOTE 1)
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
