48 TB13B (TB-13B INPUT FUNCTION)
This parameter is used to select the function of terminal TB-13B. Closing TB- 13B to TB-2 activates the
TB-13B input function. The following functions can be selected.
NONE Disables the TB-13B function.
0-10VDC Selects 0-10 VDC as the AUTO speed reference input. The 0-10 VDC signal is wired
to TB-5A and TB-2.
4-20 MA Selects 4-20 mA as the AUTO speed reference input. The 4-20 mA signal is wired to
TB-5B and TB-2.
SPEED#2 Selects PRESET SPEED #2 as the AUTO speed reference.
INC FREQ Increase frequency setpoint. Used with the MOP (motor operated pot) function. Refer
to Section 14.2.6 - SPEED REFERENCE SELECTION.
JOG FWD Jog in the forward direction. Active only when drive is STOPPED. The jog speed is set
by Parameter 2 - SPEED#2.
JOG REV Jog in the reverse direction. Active only when drive is STOPPED. The jog speed is set
by Parameter 2 - SPEED#2.
When operating in JOG mode, the STOP key WILL NOT stop the drive. To stop the drive, the
contact between TB-13B and TB-2 must be opened.
49 TB13C (TB-13C INPUT FUNCTION)
This parameter is used to select the function of terminal TB-13C. Closing TB- 13C to TB-2 activates the
TB-13C input function. The following functions can be selected.
NONE Disables the TB-13C function.
0-10VDC Selects 0-10 VDC as the AUTO speed reference input. The 0-10 VDC signal is wired
to TB-5A and TB-2.
4-20 MA Selects 4-20 mA as the AUTO speed reference input. The 4-20 mA signal is wired to
TB-5B and TB-2.
SPEED#3 Selects PRESET SPEED #3 as the AUTO speed reference.
LOC SEL LOCAL SELECT - Selects LOCAL mode when Parameter 30 - CONTROL is set to
BOTH. Drive is in REMOTE mode if contact closure is not made.
RUN REV RUN REVERSE - Run in reverse direction. Requires a maintained contact closure -
close to RUN in reverse direction, open to STOP. This will cause TB-12A to function
as RUN FORWARD, also requiring a maintained contact.
STRT REV START REVERSE - Start in reverse direction. Requires a momentary contact closure
to RUN in reverse direction. A momentary STOP contact must be wired between
TB-1 and TB-2. Setting this parameter to START REVERSE causes TB-12A to
function as START FORWARD, also requiring a momentary contact closure to RUN
in forward direction.
63
