5.0 MICRO SERIES RATINGS
115/230 & 230V (SINGLE PHASE) VOLT MICRO SERIES RATINGS
MODEL
INPUT OUTPUT
(120/240 Vac, 50-60 Hz) (0-230 Vac)
NOMINAL
FOR MOTORS CURRENT NOMINAL
CATALOG RATED INPUT (AMPS) POWER CURRENT POWER
NUMBER HP kW PHASE (NOTE 1) (KVA) (AMPS) (KVA)
174930
174996* 0.25 0.18 1 6.0/3.0 0.7 1.4/1.4 0.6
174519**
174997
174998* .50 0.37 1 9.2/4.6 1.1 2.2/2.2 0.9
174520**
174391
174999* 1 0.75 1 16.2/8.1 1.9 4.0/4.0 1.6
174521**
174932
174515* 1.5 1.1 1 21.0/10.4 2.5 5.2/5.2 2.1
174517**
MODEL
INPUT OUTPUT
(200/240 Vac, 50-60 Hz) (0-200/230 Vac)
174933
174475* 2 1.5 1 17.1/14.9 3.6 7.8/6.8 2.7
174525**
174934
174729* 3 2.2 1 24/21 5.0 11.0/9.6 3.8
174526**
NOTE 1: For 115/230 Vac, the higher current rating is for 120 Vac input and the lower current rating is for 240 Vac input.
NOTE 2: See Section 8.0 for recommended fuse type.
* = NEMA 4/12 ENCLOSURE
** = NEMA 4X ENCLOSURE
OTHERS ARE NEMA 1 ENCLOSURE
