2.Align the right panel(C) and left panel(G) into
bottom(H) using 4pcs M6X30 screws(AA) and
4pcs M6 washers(CC).Be sure not to over
tighten-you may need to adjust the panels
later on to ensure proper alignment.
3.Assemble 4pcs adjust feet(L).
ASSEMBLY INSTRUCTIONS
FF
H
1.
7
Attach propane tank straps(FF) to the bottom
plate(H) in two cross corners as shown.
C
AA
CC
G
H
K
To Next Page
