XTX-7500 – USER MANUAL – ENGLISH
SPECIFICATIONS
8. SPECIFICATIONS
XTX-7500UHD
PANEL
Diagonal Size (Inch) 75“
Backlight Edge LED
Aspect Ratio 16:9
Input Resolution 3840 x 2160 @ 60Hz
Response Time 8 ms
Brightness 370 cd/m
2
Contrast Ratio 2500:1
Viewing Angle 178º (H)/178º (V)
Supported Colors 1.07 Billion colors
Display Orientation Landscape compatible
TOUCH SYSTEM
Interface 2 x Touch USB
Touch InGlass™ touch technology; 20 touch points, 4 passive pens
Glass 3.0 mm Chemically-strengthened AGC Glass
Supported Operating System Windows 7/8/8.1/10, Mac 10.10, 10.11, 10.12
AUDIO
Built-in Speakers 2x20W front facing
CONNECTIVITY
Video 3x HDMI 2.0 / 1 x DisplayPort / 1 x VGA
Audio Audio Out / SPDIF Out / PC Audio In
Control IR Extender / RS232 / Ethernet / Touch USB
OPS slot Yes
CONFERENCING
Camera 2 Full HD wide angle cameras, 1080p@30Hz (linked to OPS)
Microphone
High performance 4 channel array with Acoustical Echo Cancelling,
Automatic Gain Control and Noise Suppression (linked to OPS)
PHYSICAL SPECIFICATIONS
Dimensions (mm) 1854 (W) x 999 (H) x 106 (D)
Weight Net: 83 kg; Gross: 96 kg
Wall Mount 600mm x 400mm / 600mm x 600mm VESA
Fanless Design Yes
OSD FUNCTIONS
OSD Languages English, French, German, Dutch
Source Auto Detect Function Yes
OSD Key Lock Function Yes
POWER
Power Supply AC100-240V (Worldwide), 6A 50/60Hz
Maximum Power Consumption ≤ 320 W
Standby ≤ 0.5 W
ENVIRONMENTAL
Operating Temperature 0 °C ~ 40 °C
Storage Temperature -20 °C ~ 60 °C
Humidity 35% ~ 85% RH
