5
Screw all legs into the threaded inserts. HAND TIGHTEN.
TWIN, FULL, & QUEEN SIZES (6 LEGS)
HEAD
HEAD
FOOT
FOOT
KING (9 LEGS)
7
Extend power cord out head end of base.
POWER CORDS MUST
NOT INTERFERE WITH
ANY ADJUSTABLE BASE
MECHANISMS. DO NOT
WEAVE CORDS THROUGH
BASE STRUCTURE.
NOTE
HEAD
FOOT
If unassembled, plug remote control cord and power supply cord
into the two base motor cables. Pivot cable latch downward and
snap cable latch in closed position.
6
DC Power
ALIGN PINS BEFORE
INSERTING PLUGS.
WARNING
!
11
12
13
Operate remote control to test
base functions. See Remote
Control User Guide for
programming instructions.
Lower base to at position.
Insert the mattress retainer into the holes at the foot end of
the base. Insert the side mattress retainers into the holes on
the sides of the foot end of the base.
AN ELECTRICAL SURGE
PROTECTION DEVICE IS
RECOMMENDED (NOT INCLUDED).
NOTE
291-0101-B EDR 16952 2/23
© 2023 Leggett & Platt, Inc. Adjustable Bed Group
CUSTOMER SERVICE toll free: (844) 628-8376
10
Plug power cord into power outlet.
NOTE
Inner holes on head end of base
are to be used for headboard
bracket installation.
8
9
TEAM LIFT
