3 100 81
3 100 83
3 100 82
3 100 84
Battery
Number of batteries 1
Battery type lead-acid sealed without maintenance (VRLA)
Unitary capacity 12 Vdc - 7.2 Ah
Rated Battery Voltage 12 Vdc
Backup time 10 min (calculated with one typical workstation)
Protection against total discharge
Typical recharge time 4-6 hours
Communication and management
Interface one pushbutton and two LEDs
Alarms Visual (LED), Audible (buzzer)
Protections
Against overload, overvoltage and short-circuit
Replaceable input fuse (T5AL250V)
Backfeed
Overtemperature
Mechanical characteristics
Dimensions W x H x D (mm) 190 x 89.5 x 296
Net weight (kg) 5 5,5
Environmental conditions
Operating temperature
+0 ºC to +40 ºC
+32 ºF to +104 ºF
Operating relative humidity <95% (non-condensing)
Storage temperature
+20 ºC to +25 ºC
+ 68 ºF to +77 ºF
Noise level at 1 m < 40 dB
IP code IP 20
Reference directive and standards
Safety
2014/35/EU Directive
EN 62040-1
EMC
2014/30/EU Directive
EN 62040-2
