37
EN
KEOR SP
3 101 80 3 101 83 3 101 86 3 101 89 3 101 92
3 101 81 3 101 84 3 101 87 3 101 90 3 101 93
3 101 82 3 101 85 3 101 88 3 101 91 3 101 94
Overload capacity
during normal mode:
automatic shutdown after 5 minutes with load>100%
automatic shutdown after 5 seconds with load>120%
immediate shutdown for short-circuit
during battery mode:
immediate shutdown
Batteries
Number of batteries 1 2
Battery type 6-cell VRLA (valve-regulated lead-acid), maintenance free
Battery voltage/capacity
12Vdc -
7 Ah
12Vdc -
9 Ah
12Vdc -
7 Ah
12Vdc -
9 Ah
Backup time 10 min. (calculated with one typical workstation)
Protection against total discharge
Typical recharge time 4-6 hours
Communication and management
Interface two pushbuttons and four LEDs
USB HID type B
Alarms Visual (LEDs), Audible (buzzer)
Mechanical characteristics
Dimensions W x H x D (mm) 20 x 138 x 330 148 x 173 x 380
Net weight (kg) 4.8 5.5 8.3 9.6 10.3
Environmental conditions
Operating temperature (°C) 0 to +40
Operating relative humidity <95% (non-condensing)
Storage temperature (°C) +20 to +25
Noise level at 1 m < 40 dB
IP code IP 20
Reference directive and standards
Safety
2014/35/EU Directive
EN 62040-1
EMC
2014/30/EU Directive
EN 62040-2 (category C2)
