LEGRAND Triscan 488TRI3W - Page 2

Figure 2
3 wire
Auto
A
Brown
N
Blue
Red
Auto & ON
override
A
Brown
N
Blue
Red
Switch: CAT EM770
Auto & OFF
override
A
Brown
N
Blue
Red
Switch: CAT EM770
Auto & ON &
OFF switch
A
Brown
N
Blue
Red
Switch: CAT 770RS180M
CAT EMRS
Figure 5
2
120º
Ceiling
Top View Side View
Wall
90º
Top view
Traffic
Direction
124mm
82mm
108mm
127.5mm
20mm
Figure 4 Figure 6
Back view
Parallel wiring for 488TR13W
Side view
1st
2nd
Nth
120º
Ceiling
Top View Side View
Wall
90º
Figure 3
A
Brown
N
Blue
Red
Brown
Blue
Red
Brown
Blue
Red
Switch: CAT 770RS180M
CAT EMRS
124mm
82mm
108mm
127.5mm
20mm
