UNBALANCED SIGNAL ROUTING
Unbalanced signal lines predominate
when instruments such as guitars, basses
and keyboards are used.
These signal lines have two conducting
cores.
The signal itself is present on the signal
conductor and is connected to the tip of
the jack plug.
The second core, which is connected to
the sleeve of the jack plug, screens the
signal conductor and constitutes the sig-
nal ground.
UNBALANCED SIGNAL ROUTING
Tip
Signal in phase
Sleeve
Ground
JACK JACK
Cable
Sleeve
Sleeve
Ground
Tip
Tip
Signal in phase
