2
CAUTION: Risk of
electric shock
CAUTION: (Refer to
accompanying documents)
CAUTION: Replace with same type and rating fuse
(IEC 60127-2/SS 3 standard).
1.0 Introduction
Thank you for purchasing the CM E from Leica Microsystems. The
Leica CM E Compound Microscope combines exclusive design
features and a full range of accessories making it a truly versatile,
quality instrument for advanced academic and routine clinical
applications.
CAUTION: This instrument should only be used as described.
Hazards may result if used improperly.
2.0 Unpacking
Carefully remove the microscope components from the packing carton.
Check the components against the following standard equipment list:
1. Stand: includes focusing 5. Condenser
mechanism, graduated 6. Immersion oil
mechanical stage, 8. Dust cover
nosepiece and integral 9. Power cord (as ordered)
illumination system. 10. Blue filter
2. Viewing body 11. 3mm Allen wrench
3. Objectives
4. Eyepiece(s)
Optional items such as contrast accessories, camera adapters
and systems and carrying cases are not shipped as part of the
standard equipment. These items are delivered in separate
packages.
Please do not discard any of the packing materials. They should
be used for safely storing and transporting the instrument
should the need arise.
3.0 Preparation for Use
3.1 Viewing Body
Attach the viewing body to the stand by backing off the set screw on
top of the stand with the tool provided. Then insert the dovetail of the
viewing body into the stand support and tighten the set screw firmly
without forcing it. This precisely locates the body on the optical axis
of the microscope, regardless of the selected orientation. After the
body is attached, insert the eyepieces into the eyetubes. Attach the
power cord and turn on the CM E using the swich on the back of the
instrument. The knurled dial on the lower left side will control the
illumination intensity.
English
Explanation of Warning Symbols
Leica CM E
Instruction Manual
Contents
1.0 Introduction ........................................................................2
2.0 Unpacking ........................................................................2
3.0 Preparation For Use 3.1 Viewing Body.....................................2
3.2 Installing Objectives.........................3
3.3 Substage Condenser .......................3
3.4 Filters ...................................................3
4.0 Operation ...............................................................3
5.0 Care of Microscope 5.1 General................................................3
5.2 Mechanical Maintenance..............4
5.3 Lamp Replacement ..........................4
5.4 Electrical Considerations/
Equipment Ratings ...........................4
6.0 Fuse Replacement ........................................................................5
7.0 Anti-Fungus / Mold ........................................................................5
Warranty
8.0 Notes ........................................................................5
