Leica GM30 User Manual

GR30/GM30/GR50, Installation
32
Tripod The instrument has a built-in Tripod mount to allow attachment to all Leica Geosys-
tems Tripods.

When using the instrument on a tripod, the rubber bumpers must be on.
a) AR10/AS10(shown)
b) GNSS antenna carrier with 5/8 inch screw
c) Tribrach
d) Tripod
e) Antenna cable
f) GR30/GM30/GR50
GR10_019
a
b
c
d
e
f

Leica GM30 Specifications

General

Type	GNSS Receiver
Channels	555
GPS L1/L2/L5	Yes
GLONASS L1/L2	Yes
Galileo E1/E5a/E5b/E6	Yes
BeiDou B1/B2/B3	Yes
QZSS L1/L2/L5	Yes
SBAS	Yes
Update Rate	Up to 20 Hz
Operating Temperature	-40°C to +65°C
Ingress Protection	IP67
Battery Life	Up to 10 hours
Position Accuracy (RTK)	8 mm + 1 ppm (Horizontal), 15 mm + 1 ppm (Vertical)
Communication Interfaces	Bluetooth, Ethernet, USB
