GR10/GR25, Operation
59
7Operation
7.1 Using the Web Interface
Web Interface login Entering the instruments IP address or host name in a browser window displays the
web interface login page.
• The home page is also shown after user login.
• For a partially restricted web interface access, the login as guest button can be
used. This allows access to all instrument status information.
The login page is not shown if the web interface access level is set to unre-
stricted. The web interface home page is opened directly. For security reasons
it is not recommended to set the web interface access to Unrestricted. To
change the access setting, go to Receiver Setup / Access Management /
Access settings.
Web Interface -
User Interface
The default appearance of the Web interface consists of the following main compo-
nents.
Header
The header contains general information about the instrument.
• Instrument type
• Loaded firmware version
•Site code
• Current system date and time
Menu Bar
The menu bar at the top of the display contains links to the home page, all status
information, GNSS management pages, receiver setup, help and support. The menus
are extended when the mouse is moved over a menu item. If a link is not available to
a logged in user, it is greyed out and not accessible. Which menu items are available
is dependent on
•the selected Access to Web interface level, and
•the selected Web interface user level of the logged in user.
a) Header
b) Menu Bar
c) Status: General
d) Status: Tracking
e) Status: Event log
