EN
79
Camera operation
IMAGE FIELD SELECTOR
The image fi eld selector extends the possibilities of this built-in
universal viewfi nder: at any time, you can view frames that do not
belong to the current lens. You can then see immediately if, for
image composition reasons, it would be better to photograph the
relevant subject using a diff erent focal length.
If the lever is rotated outwards, i.e. away from the lens, the image
fi eld limits for 35 and 135mm focal length are shown.
If the lever is rotated to the vertical, centered position, the image
fi eld limits for 50 and 75mm focal length are shown. If the lever is
rotated inward, i.e. toward the lens, the image fi eld limits for 28
and 90mm focal length are shown.
35mm + 135mm
