Leica RTC360 Quick Guide

The RTC360/RTC360 LT instrument contains the following laser product:
Laser product Laser class
EDM (Electronic Distance Measurement) module
Class 1
The classication is in accordance with IEC 60825-1 (2014-05).
60°
60°
0°
0°
360°
360°
90°
b
a
c
0016195_003
a Laser beam
b Vertical laser scanning area
c Horizontal laser scanning area
Laser products
Locations of laser
apertures
7 Important Information about your Instrument
en

Leica RTC360 Specifications

General

Scan Rate	up to 2 million points per second
HDR Imaging	yes
Field of View	360° x 300°
Type	3D Laser Scanner
Automatic Targetless Field Registration	yes
Protection Class	IP54
Measurement Range	0.5 – 130 m
Laser Class	Class 1
Laser Wavelength	1550 nm
Scan Time	less than 2 minutes
Camera	Integrated HDR camera
Weight	5.35 kg (11.8 lbs)
