Description of tool
1. Power supply cord
2. On/off switch
3. Potentiometer for
temperature adjustment
4. Handle
5. Air slide
6. Air filter
7. Rubber stand
8. Heater tube
6
8
5
7
2
34
1
3
OPERATION Leister MISTRAL
Assembling
• Assembly must ensure that:
– only cold air is supplied
– no (hot air) backup occurs
– the tool is not subjected to a hot air flow from another tool
• The tool is protected against mechanical vibration and shaking
• Assembly dimensions in mm
MISTRAL
