CHAPTER 4
Final checks
11. To adjust the saddle height, loosen the bolt on
the seat post collar using a 5mm allen key and
remove the seat post completely, insert the seat
post to the desired height and tighten the collar to
5Nm. Check the saddle is correctly positioned and
retighten the 6mm bolt at the top of the seat post
(located under the saddle) to 17Nm.
12. To operate the lights, make sure the battery is
charged and in the bike. Power up the bike, once
the control screen has turned on hold down the
plus (+) button for 2 seconds to turn on both the
front and rear lights. To turn off the lights hold down
the plus (+) button for 2 seconds and the lights will
switch off.
IMAGES
Chapter 4
10
10.1
8
9
