Spare Part List (ACTIVE VERSIONS)Spare Part List (ACTIVE VERSIONS)

Spare Part List (ACTIVE VERSIONS)

Code Description

AccessoriesAccessories

Accessories

277334 Owner’s Manual

130274 Mains Cable (EU)

130276 Mains Cable (US)

AV-12AAV-12A

AV-12A

Amplifier AssemblyAmplifier Assembly

Amplifier Assembly

737103737103

737103

200W Amplifier Module (EU)200W Amplifier Module (EU)

200W Amplifier Module (EU)

737104737104

737104

200W Amplifier Module (US)200W Amplifier Module (US)

200W Amplifier Module (US)

778146 * Amplifier Cables Assembly

768211768211

768211

200W Supply Board (Pcb#313061)200W Supply Board (Pcb#313061)

200W Supply Board (Pcb#313061)

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

140081 ** H 2c P=10 Terminal Block

140069 ** H 3c P=10mm Terminal Block

110119 ** Fuse Clip 10A max (EU) (US)

100060 ** 7815 +15V 1A Voltage Regulator

100049 ** 7915 -15V 1A Voltage Regulator

080605 ** KBL02 4A 200V Rectifier Diode Bridge

080156 ** 1N4002 1A 100V Rectifier Diode

030560 ** 4700u 80v 20% Snap-In Electrolytic Capacitor

030526 ** 2200u 35v 20% Snap-In Electrolytic Capacitor

020250 ** 10n 400V 10% MKT Polyester Capacitor

768207768207

768207

Inputs Board (Pcb#313058)Inputs Board (Pcb#313058)

Inputs Board (Pcb#313058)

141189 ** Hor Female XLR-Jack Socket (NCJ6FK-H Neutrik)

141186 ** Hor Male XLR Socket (NC3MAH Neutrik)

140929 ** 9 Contacts Vert Male Connector

120857 ** Vertical Male Faston 6.3mm

110267 ** 1sw 2pos Horizontal Slider Switch

100061 ** TL072 Dual J-Fet Operational Amplifier

080743 ** 3mm Wide Diffused Green Led

080742 ** Led 3mm Wide Diffused Red-Grn

080293 ** 15V 1W 5% Zener Diode

074570 ** 5K 31steps Linear Potentiometer

070245 ** 100K 20% Vertical Linear Trimmer

042706 ** 80K6 1/4W 1% Metalized Film Resistor

042630 ** 17K4 1/4W 1% Metalized Film Resistor

042625 ** 15K0 1/4W 1% Metalized Film Resistor

020250 ** 10n 400V 10% MKT Polyester Capacitor

727606727606

727606

200W Amplifier Board (Pcb#319064)200W Amplifier Board (Pcb#319064)

200W Amplifier Board (Pcb#319064)

768214 ** 200W Amplifier Board (Pcb#319064) without Power Transistors

141102 *** 6 Contacts Vert Male Connector

140929 *** 9 Contacts Vert Male Connector

110316 *** Relay 24V / 1 Switch no 16A 250V

100904 *** LM393 Dual Comparator

100061 *** TL072 Dual J-Fet Operational Amplifier

090917 *** MJE350 TO126 Pnp Transistor

090916 *** MJE340 TO126 Npn Transistor

090201 *** 2N5401 TO92 Pnp Transistor

090200 *** 2N5550 TO92 Npn Transistor

090194 *** BC560 TO92 LN Pnp Transistor

090183 *** BC550 TO92 LN Npn Transistor

090153 *** BC327 TO92 Pnp Transistor

080901 *** VTL5C4 Analog Optoisolator

080245 *** 7V5 1W 5% Zener Diode

080171 *** FE6B 6A 100V Fast Recovery Diode

080156 *** 1N4002 1A 100V Rectifier Diode

080103 *** 1N4148 100mA 75V Signal Diode

070105 *** 470E 20% Vertical Linear Trimmer

060591 *** 8K2 2W 10% Resistor

060051 *** 0E22 5W 5% Wire Resistor

042695 *** 56K2 1/4W 1% Metalized Film Resistor

042685 *** 47K5 1/4W 1% Metalized Film Resistor

042605 *** 10K0 1/4W 1% Metalized Film Resistor

030715 *** 1000u 6v3 20% Vert Electrolytic Capacitor

340154 ** TO3/TO218 Mica Washer

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

090920 ** MJE802 TO126 Npn Darl Transistor

090919 ** MJE15031 TO220 Pnp Transistor

090918 ** MJE15030 TO220 Npn Transistor

090913 ** MJE4352 TO218 Pnp Transistor

090912 ** MJE4342 TO218 Npn Transistor

090863 ** TIP36C TO218 Pnp Transistor

090862 ** TIP35C TO218 Npn Transistor

080821 ** Ptc 90 PTH59F04BE222TS

667697 * Rear Panel

237077237077

237077

Transformer 230Vac 200W (EU)Transformer 230Vac 200W (EU)

Transformer 230Vac 200W (EU)

237078237078

237078

Transformer 115Vac 200W (US)Transformer 115Vac 200W (US)

Transformer 115Vac 200W (US)

210215 * Adhesive Rubber Foam 10x1.9mm (Specify mt)

210212 * Slider Switch Adhesive Gasket

110614 * Mains Socket

110291 * Power Switch

110029 * T4A Fuse 5x20mm (EU)

110014 * T2.5A Fuse 5x20mm (EU)

110036 * T4A Fuse 6.3x32mm (US)

110035 * T2.5A Fuse 6.3x32mm (US)

080607 * KBPC25 25A 200V Rectifier Diode Bridge

020491 * 100nF 10% 250Vac Polyester Capacitor

Box AssemblyBox Assembly

Box Assembly

778112 Cables Assembly

768202768202

768202

Crossover Filter Board (Pcb#313063) AV-12/4 OhmCrossover Filter Board (Pcb#313063) AV-12/4 Ohm

Crossover Filter Board (Pcb#313063) AV-12/4 Ohm

667702 Handle

667700 Grid

659027 White Pot Knob

657271 Box

657270 EWT(TM) Elliptical Horn

229037229037

229037

1" 4ohm Horn Tweeter1" 4ohm Horn Tweeter

1" 4ohm Horn Tweeter

227056227056

227056

12" 4ohm Woofer Speaker12" 4ohm Woofer Speaker

12" 4ohm Woofer Speaker

210242 Filler for Speaker Box (Specify m²)

210217 Black Sealer (specify mt)

210215 Adhesive Rubber Foam 10x1.9mm (Specify mt)

210211 Gasket between Tweeter and Horn

120964 M4i M5e x17.5mm Threaded Pin

120148 Screw M5x65mm for Handle

120147 Screw M4x8mm for Speakers

AV-15AAV-15A

AV-15A

Amplifier AssemblyAmplifier Assembly

Amplifier Assembly

737105737105

737105

350W Amplifier Module (EU)350W Amplifier Module (EU)

350W Amplifier Module (EU)

737106737106

737106

350W Amplifier Module (US)350W Amplifier Module (US)

350W Amplifier Module (US)

778146 * Amplifier Cables Assembly

768212768212

768212

350W Supply Board (Pcb#313061)350W Supply Board (Pcb#313061)

350W Supply Board (Pcb#313061)

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

140081 ** H 2c P=10 Terminal Block

140069 ** H 3c P=10mm Terminal Block

110119 ** Fuse Clip 10A max (EU) (US)

100060 ** 7815 +15V 1A Voltage Regulator

100049 ** 7915 -15V 1A Voltage Regulator

080606 ** GBU8D 8A Rectifier Diodes Bridge

080293 ** 15V 1W 5% Zener Diode

080156 ** 1N4002 1A 100V Rectifier Diode

060403 ** 180E 3W 10% Resistor

030560 ** 4700u 80v 20% Snap-In Electrolytic Capacitor

030555 ** 4700u 50V 20% Snap-In Electrolytic Capacitor

768208768208

768208

Inputs Board (Pcb#313058)Inputs Board (Pcb#313058)

Inputs Board (Pcb#313058)

141189 ** Hor Female XLR-Jack Socket (NCJ6FK-H Neutrik)

141186 ** Hor Male XLR Socket (NC3MAH Neutrik)

140929 ** 9 Contacts Vert Male Connector

120857 ** Vertical Male Faston 6.3mm

110267 ** 1sw 2pos Horizontal Slider Switch

100061 ** TL072 Dual J-Fet Operational Amplifier

080743 ** 3mm Wide Diffused Green Led

080742 ** Led 3mm Wide Diffused Red-Grn

080293 ** 15V 1W 5% Zener Diode

074570 ** 5K 31steps Linear Potentiometer

070245 ** 100K 20% Vertical Linear Trimmer

042715 ** 82K5 1/4W 1% Metalized Film Resistor

042630 ** 17K4 1/4W 1% Metalized Film Resistor

042625 ** 15K0 1/4W 1% Metalized Film Resistor

727607727607

727607

350W Amplifier Board (Pcb#319064)350W Amplifier Board (Pcb#319064)

350W Amplifier Board (Pcb#319064)

768215 ** 350W Amplifier Board (Pcb#319064) without Power Transistors

141102 *** 6 Contacts Vert Male Connector

140929 *** 9 Contacts Vert Male Connector

110316 *** Relay 24V / 1 Switch no 16A 250V

100904 *** LM393 Dual Comparator

100061 *** TL072 Dual J-Fet Operational Amplifier

090917 *** MJE350 TO126 Pnp Transistor

090916 *** MJE340 TO126 Npn Transistor

090201 *** 2N5401 TO92 Pnp Transistor

090200 *** 2N5550 TO92 Npn Transistor

090194 *** BC560 TO92 LN Pnp Transistor

090183 *** BC550 TO92 LN Npn Transistor

090153 *** BC327 TO92 Pnp Transistor

080901 *** VTL5C4 Analog Optoisolator

080245 *** 7V5 1W 5% Zener Diode

080171 *** FE6B 6A 100V Fast Recovery Diode

080156 *** 1N4002 1A 100V Rectifier Diode

080103 *** 1N4148 100mA 75V Signal Diode

070105 *** 470E 20% Vertical Linear Trimmer

060591 *** 8K2 2W 10% Resistor

060051 *** 0E22 5W 5% Wire Resistor

042695 *** 56K2 1/4W 1% Metalized Film Resistor

042687 *** 49K9 1/4W 1% Metalized Film Resistor

042605 *** 10K0 1/4W 1% Metalized Film Resistor

030715 *** 1000u 6v3 20% Vert Electrolytic Capacitor

340783 ** TO264 Mica Washer

340154 ** TO3/TO218 Mica Washer

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

090924 ** MJL21194 TO264 Npn Transistor

090923 ** MJL21193 TO264 Pnp Transistor

090920 ** MJE802 TO126 Npn Darl Transistor

090919 ** MJE15031 TO220 Pnp Transistor

090918 ** MJE15030 TO220 Npn Transistor

090863 ** TIP36C TO218 Pnp Transistor

090862 ** TIP35C TO218 Npn Transistor

080821 ** Ptc 90 PTH59F04BE222TS

667698 * Rear Panel

237068237068

237068

Transformer 230Vac 350W (EU)Transformer 230Vac 350W (EU)

Transformer 230Vac 350W (EU)

237069237069

237069

Transformer 115Vac 350W (US)Transformer 115Vac 350W (US)

Transformer 115Vac 350W (US)

210215 * Adhesive Rubber Foam 10x1.9mm (Specify mt)

210212 * Slider Switch Adhesive Gasket

110614 * Mains Socket

110291 * Power Switch

110029 * T4A Fuse 5x20mm (EU)

110018 * T6.3A Fuse 5x20mm (EU)

110037 * T6.3A Fuse 6.3x32mm (US)

110036 * T4A Fuse 6.3x32mm (US)

080607 * KBPC25 25A 200V Rectifier Diode Bridge

020491 * 100nF 10% 250Vac Polyester Capacitor

Box AssemblyBox Assembly

Box Assembly

778112 Cables Assembly

768204768204

768204

Crossover Filter Board (Pcb#313062) AV-15/4 OhmCrossover Filter Board (Pcb#313062) AV-15/4 Ohm

Crossover Filter Board (Pcb#313062) AV-15/4 Ohm

667703 Handle

667701 Grid

659027 White Pot Knob

657272 Box

657270 EWT(TM) Elliptical Horn

229036229036

229036

1" 8ohm Horn Compression Driver1" 8ohm Horn Compression Driver

1" 8ohm Horn Compression Driver

227058227058

227058

15" 4ohm Woofer Speaker15" 4ohm Woofer Speaker

15" 4ohm Woofer Speaker

210242 Filler for Speaker Box (Specify m²)

210217 Black Sealer (specify mt)

210215 Adhesive Rubber Foam 10x1.9mm (Specify mt)

210211 Gasket between Tweeter and Horn

120965 M4i M5e x24mm Threaded Pin

120148 Screw M5x65mm for Handle

120147 Screw M4x8mm for Speakers

AV-15SAAV-15SA

AV-15SA

Amplifier AssemblyAmplifier Assembly

Amplifier Assembly

737107737107

737107

350W Amplifier Module (EU)350W Amplifier Module (EU)

350W Amplifier Module (EU)

737108737108

737108

350W Amplifier Module (US)350W Amplifier Module (US)

350W Amplifier Module (US)

778147 * Amplifier Cables Assembly

768213768213

768213

350W Supply Board (Pcb#313061)350W Supply Board (Pcb#313061)

350W Supply Board (Pcb#313061)

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

100060 ** 7815 +15V 1A Voltage Regulator

100049 ** 7915 -15V 1A Voltage Regulator

080606 ** GBU8D 8A Rectifier Diodes Bridge

080293 ** 15V 1W 5% Zener Diode

080156 ** 1N4002 1A 100V Rectifier Diode

060403 ** 180E 3W 10% Resistor

030884 ** 10000U 80V 20% Snap-In Electrolytic Capacitor

030555 ** 4700u 50V 20% Snap-In Electrolytic Capacitor

768210 * Controls & Crossover Board (Pcb#313060)

140929 ** 9 Contacts Vert Male Connector

140908 ** 6 Contacts Vert Male Small Connector

140873 ** 4 Contacts Vert Male Connector

110305 ** Relay 12V / 2 Switch 1A 250V

100919 ** MC33078 Dual LN Operational Amplifier

100084 ** TL074 Quad J-Fet Operational Amplifier

100061 ** TL072 Dual J-Fet Operational Amplifier

100019 ** TL071 LN J-Fet Operational Amplifier

080743 ** 3mm Wide Diffused Green Led

080742 ** Led 3mm Wide Diffused Red-Grn

080103 ** 1N4148 100mA 75V Signal Diode

075820 ** 4x100K 16mm Hor Rotary Alog Potentiometer

074570 ** 5K 31steps Linear Potentiometer

070241 ** 100K 20% Horizontal Linear Trimmer

042717 ** 88K7 1/4W 1% Metalized Film Resistor

042625 ** 15K0 1/4W 1% Metalized Film Resistor

042617 ** 13K0 1/4W 1% Metalized Film Resistor

042605 ** 10K0 1/4W 1% Metalized Film Resistor

042565 ** 4K99 1/4W 1% Metalized Film Resistor

042555 ** 4K22 1/4W 1% Metalized Film Resistor

768209768209

768209

Inputs Board (Pcb#313059)Inputs Board (Pcb#313059)

Inputs Board (Pcb#313059)

141189 ** Hor Female XLR-Jack Socket (NCJ6FK-H Neutrik)

141186 ** Hor Male XLR Socket (NC3MAH Neutrik)

140935 ** 6 Contacts Hor Male Connector

140872 ** 4 Contatcs Hor Male Connector

110267 ** 1sw 2pos Horizontal Slider Switch

080293 ** 15V 1W 5% Zener Diode

727607727607

727607

350W Amplifier Board (Pcb#319064)350W Amplifier Board (Pcb#319064)

350W Amplifier Board (Pcb#319064)

768215 ** 350W Amplifier Board (Pcb#319064) without Power Transistors

141102 *** 6 Contacts Vert Male Connector

140929 *** 9 Contacts Vert Male Connector

110316 *** Relay 24V / 1 Switch no 16A 250V

100904 *** LM393 Dual Comparator

100061 *** TL072 Dual J-Fet Operational Amplifier

090917 *** MJE350 TO126 Pnp Transistor

090916 *** MJE340 TO126 Npn Transistor

090201 *** 2N5401 TO92 Pnp Transistor

090200 *** 2N5550 TO92 Npn Transistor

090194 *** BC560 TO92 LN Pnp Transistor

090183 *** BC550 TO92 LN Npn Transistor

090153 *** BC327 TO92 Pnp Transistor

080901 *** VTL5C4 Analog Optoisolator

080245 *** 7V5 1W 5% Zener Diode

080171 *** FE6B 6A 100V Fast Recovery Diode

080156 *** 1N4002 1A 100V Rectifier Diode

080103 *** 1N4148 100mA 75V Signal Diode

070105 *** 470E 20% Vertical Linear Trimmer

060591 *** 8K2 2W 10% Resistor

060051 *** 0E22 5W 5% Wire Resistor

042695 *** 56K2 1/4W 1% Metalized Film Resistor

042687 *** 49K9 1/4W 1% Metalized Film Resistor

042605 *** 10K0 1/4W 1% Metalized Film Resistor

030715 *** 1000u 6v3 20% Vert Electrolytic Capacitor

340783 ** TO264 Mica Washer

340154 ** TO3/TO218 Mica Washer

340079 ** TO220 Mica Washer

340078 ** TO220 Insulated Bush

090924 ** MJL21194 TO264 Npn Transistor

090923 ** MJL21193 TO264 Pnp Transistor

090920 ** MJE802 TO126 Npn Darl Transistor

090919 ** MJE15031 TO220 Pnp Transistor

090918 ** MJE15030 TO220 Npn Transistor

090863 ** TIP36C TO218 Pnp Transistor

090862 ** TIP35C TO218 Npn Transistor

080821 ** Ptc 90 PTH59F04BE222TS

667699 * Rear Panel

237068237068

237068

Transformer 230Vac 350W (EU)Transformer 230Vac 350W (EU)

Transformer 230Vac 350W (EU)

237069237069

237069

Transformer 115Vac 350W (US)Transformer 115Vac 350W (US)

Transformer 115Vac 350W (US)

210215 * Adhesive Rubber Foam 10x1.9mm (Specify mt)

210212 * Slider Switch Adhesive Gasket

110614 * Mains Socket

110291 * Power Switch

110029 * T4A Fuse 5x20mm (EU)

110018 * T6.3A Fuse 5x20mm (EU)

110037 * T6.3A Fuse 6.3x32mm (US)

110036 * T4A Fuse 6.3x32mm (US)

080607 * KBPC25 25A 200V Rectifier Diode Bridge

020491 * 100nF 10% 250Vac Polyester Capacitor

Box AssemblyBox Assembly

Box Assembly

667703 Handle

667701 Grid

659027 White Pot Knob

659026 Orange Pot Knob

657273 Box

347393 Threaded Clog (to steady on the floor)

227060227060

227060

15" 4ohm Woofer Speaker15" 4ohm Woofer Speaker

15" 4ohm Woofer Speaker

210242 Filler for Speaker Box (Specify m²)

210217 Black Sealer (specify mt)

210215 Adhesive Rubber Foam 10x1.9mm (Specify mt)

177721 Fixing Plate (to fix the Floor Bracket)

120965 M4i M5e x24mm Threaded Pin

120148 Screw M5x65mm for Handle

120147 Screw M4x8mm for Speakers

667704 Floor Bracket with Threaded Knobs

Note:Note:

Note:

Each spare part is single quantity unless otherwise specified.

Asterisk prefix explanation:

Omitted = First level spare part.

One asterisk = Second level, part of previous listed first level part.

Two asterisk = Third level, part of previous listed second level part.

Three asterisk = ............

Any request for not above mentioned part must encompass specific description including:

1) Model name,

2) Section name,

3) Module code,

4) Reference name,

5) Quantity number.

Brand	LEM
Model	Avalon AV15-4
Category	Speakers
Language	English

LEM Avalon AV15-4 User Manual

Table of Contents

Questions and Answers:

LEM Avalon AV15-4 Specifications

Related product manuals
