Spare Part List
Legend
EU = Europe version 230V
code description
Miscellaneous Parts
130285 Mains Cable (EU)
110291 16A 250Vac Bipolar Power Switch
020493 100n 250Vac MKP EMI Capacitor
110003 T3.15A Fuse 5X20mm (Procon400P)
110029 T4A Fuse 5X20mm (Procon750P)
110023 T8A Fuse 5X20mm (Procon1000P)
110030 T10A Fuse 5X20mm (Procon1250P)
110040 T12A Fuse 6.3X32mm (Procon1500P)
110041 T15A Fuse 6.3X32mm (Procon1800P/2200P)
HGB110100 Panel Fuse Holder for 5x20mm fuses
HGB110101 Panel Fuse Holder for 6.3x32mm fuses
HGB238007 Transformer 230Vac 550W (EU) (Procon 400P)
HGB238008 Transformer 230Vac 920W (EU) (Procon 750P)
HGB238009 Transformer 230Vac 1480W (EU) (Procon 1000P)
HGB238010 Transformer 230Vac 1660W (EU) (Procon 1250P)
HGB238011 Transformer 230Vac 2090W (EU) (Procon 1500P)
HGB238012 Transformer 230Vac 2680W (EU) (Procon 1800P)
HGB238013 Transformer 230Vac 3170W (EU) (Procon 2200P)
HGB080801 KBPC3510 35A 1000V Rectifi er Diode Bridge (Procon 400P...1800P)
HGB080802 KBPC5010 50A 1000V Rectifi er Diode Bridge (Procon 2200P)
141200 Speakon Socket (NL4MP Neutrik)
HGB347001 Volume Knob
HGB140000 Dual Red/Blk Binding Post
HGB110300 12Vdc 0.25A 80x25mm Fan (Procon 400P...1000P)
HGB110302 12Vdc 0.45A 80x25mm Fan (Procon 1250P…2200P)
HGB110305 Thermostat 65° NO 67F065 Airpax
HGB110306 Thermostat 95° NC 67L095 Airpax
110360 Fan Grid 80mm
HGB030004 10000uF 160V Electrolytic Capacitor Screw-Terminal (Procon2200P)
HGB030003 10000uF 120V Electrolytic Capacitor Screw-Terminal (Procon1800P)
HGB030002 10000uF 110V Electrolytic Capacitor Screw-Terminal (Procon1250P/1500P)
HGB030001 10000uF 100V Electrolytic Capacitor Screw-Terminal (Procon1000P)
Soft Start Board
HGB768015 Soft Start Board (Pcb# HQ7.7365) (Procon 1000P…2200P)
HGB110303 Relay 12V / 1 Switch 30A 240Vac NO
080156 1N4002 1A 100V Rectifi er Diode
030862 6800uF 25V Electrolytic Capacitor
HGB061002 40E 10W 5% Wire Resistor
VCC Capacitor Board
HGB768035 VCC Capacitor Board (Pcb# HQ7.7349) (Procon 400P)
HGB768032 VCC Capacitor Board (Pcb# HQ7.7349) (Procon 750P)
030884 10000uF 80V Electrolytic Capacitor Snap-In (Procon750P)
HGB030005 12000uF 63V Electrolytic Capacitor Snap-In (Procon400P)
HGB768016 XLR Input Board (Pcb# HQ7.7347)(All Models)
HGB140002 Hor Female XLR Socket
Display Board
HGB768001 Display Board (PCBA HQ7.7407)(All Models)
HGB075001 10KA RK16 Rotary Potentiometer K15 40CLK
HGB100001 BA6144 5-Point Led Level Meter
080705 3mm Red Led
080706 3mm Green Led
080710 3mm Yellow Led
Status Board
HGB768017 Status Board (PCBA HQ7.7367)(All Models)
080705 3mm Red Led
Input, Protection, Driver Board
HGB768036 Input, Protection, Driver Board (PCBA HQ7.7417)(Procon 400P)
HGB768033 Input, Protection, Driver Board (PCBA HQ7.7417)(Procon 750P)
HGB140004 2sw 2pos H Slider Switch
HGB140003 Jack Horizontal S-F Socket
HGB110301 Relay 12V / 2 Switch 10A 250Vac
HGB100000 TA7317P Speaker Protection Circuit
100045 7812 +12V 1A Voltage Regulator
100043 7912 -12V 1A Voltage Regulator
100971 NJM4580D Dual LN Operational Amplifi er
SKK100000 NJM2068D Dual LN Operational Amplifi er
100004 LM3080 Single Operational Transconctance Amplifi er
HGB090008 2SC2690 TO126 Npn Transistor (Procon 750P)
HGB090010 2SA1220 TO126 Pnp Transistor (Procon 750P)
HGB090000 2SC2240GR TO92 LN Npn Transistor
HGB090017 2SD667AC TO92L Npn Transistor (Procon 400P)
HGB090018 2SB647AC TO92L Pnp Transistor (Procon 400P)
090200 2N5551 TO92 Npn Transistor
HGB090019 2N3904 TO92 Npn Transistor
HGB090020 2N3906 TO92 Pnp Transistor
080272 12V 1W 5% Zener Diode
080158 1N4004 1A 400V Rectifi er Diode
080103 1N4148 100mA 75V Signal Diode
110011 T1A Fuse 5x20mm (EU)
Dual Channel Amplifier Module
HGB768034 375+375W Amplifi er Module (PCBA HQ7.7474)(Procon 400P)
HGB768037 200+200W Amplifi er Module (PCBA HQ7.7473)(Procon 750P)
HGB090008 2SC2690 TO126 Npn Transistor
HGB090010 2SA1220 TO126 Pnp Transistor
HGB090014 2SA1943 TO264 Pnp Transistor (Procon 750P)
HGB090013 2SC5200 TO264 Npn Transistor (Procon 750P)
HGB090006 2SA1941 TO3P/TO218 Pnp Transistor (Procon 400P)
HGB090005 2SC5198 TO3P/TO218 Npn Transistor (Procon 400P)
HGB090000 2SC2240GR TO92 LN Npn Transistor
HGB090004 2SA970GR TO92 LN Pnp Transistor
HGB080800 Ntc type DKF503 (Thermometrics)
080158 1N4004 1A 400V Rectifi er Diode
080103 1N4148 100mA 75V Signal Diode
HGB060089 0E43 5W 5% Wire Resistor
Input, Protection, Board
HGB768031 Input, Protection, Board (PCBA HQ7.7462)(Procon 1000P)
HGB768030 Input, Protection, Board (PCBA HQ7.7462)(Procon 1250P)
HGB768019 Input, Protection, Board (PCBA HQ7.7462)(Procon 1500P/1800P/
2200P)
HGB140004 2sw 2pos H Slider Switch
HGB140005 4sw 2pos H Slider Switch
HGB140003 Jack Horizontal S-F Socket
HGB100000 TA7317P Speaker Protection Circuit
100045 7812 +12V 1A Voltage Regulator
100043 7912 -12V 1A Voltage Regulator
100971 NJM4580D Dual LN Operational Amplifi er
HGB090008 2SC2690 TO126 Npn Transistor
090200 2N5551 TO92 Npn Transistor
090201 2N5401 TO92 Pnp Transistor
080158 1N4004 1A 400V Rectifi er Diode
080103 1N4148 100mA 75V Signal Diode
110012 T1.6A Fuse 5x20mm (EU)
Single Amplifier Module
HGB768029 CH2-500W Amplifi er Module (Pcb# HQ7.7416)(Procon 1000P)
HGB768028 CH1-500W Amplifi er Module (Pcb# HQ7.7416)(Procon 1000P)
HGB768027 CH2-625W Amplifi er Module (Pcb# HQ7.7416)(Procon 1250P)
HGB768026 CH1-625W Amplifi er Module (Pcb# HQ7.7416)(Procon 1250P)
HGB768025 CH2-750W Amplifi er Module (Pcb# HQ7.7415)(Procon 1500P)
HGB768024 CH1-750W Amplifi er Module (Pcb# HQ7.7415)(Procon 1500P)
HGB768023 CH2-900W Amplifi er Module (Pcb# HQ7.7409)(Procon 1800P)
HGB768022 CH1-900W Amplifi er Module (Pcb# HQ7.7409)(Procon 1800P)
HGB768021 CH2-1100W Amplifi er Module (Pcb# HQ7.7444)(Procon 2200P)
HGB768020 CH1-1100W Amplifi er Module (Pcb# HQ7.7444)(Procon 2200P)
HGB110304 Relay 12V / 1 Switch 30A 240Vac NO
100971 NJM4580D Dual LN Operational Amplifi er
SKK100000 NJM2068D Dual LN Operational Amplifi er
100004 LM3080 Single Operational Transconctance Amplifi er
HGB090013 2SC5200 TO264 Npn Transistor
HGB090014 2SA1943 TO264 Pnp Transistor
HGB090005 2SC5198 TO3P/TO218 Npn Transistor
HGB090006 2SA1941 TO3P/TO218 Pnp Transistor
HGB090015 2SC4793 TO220P Npn Transistor
HGB090016 2SA1837 TO220P Pnp Transistor
HGB090000 2SC2240GR TO92 LN Npn Transistor
HGB090004 2SA970GR TO92 LN Pnp Transistor
HGB090001 2SC2001K TO92 Npn Transistor
HGB090019 2N3904 TO92 Npn Transistor
HGB090020 2N3906 TO92 Pnp Transistor
080272 12V 1W 5% Zener Diode
HGB080800 Ntc type DKF503 (Thermometrics)
HGB080000 FR107 OR BA159 Fast Rec Diode 1A 1000V 500ns DO41
HGB061000 10K 4W 5% Resistor
080158 1N4004 1A 400V Rectifi er Diode
080103 1N4148 100mA 75V Signal Diode
060151 1E 5W 5% Wire Resistor
Note:
Each spare part is single quantity unless otherwise specifi ed.
Asterisk prefi x explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed fi rst level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk= ............
Any request for not above mentioned part must encompass specifi c description including:
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
