LEM T5SA User Manual

10
10. Technical specifications
Components 15" woofer
Construction
Laminated birch plywood with black scratch-resistant paint - Metal grid
Metal handles and speaker stand adapter - 4 wheels for trasportation
Dimensions mm (WxHxD) 466x600x600
Weight kg 43.5
Input
sensitivity
impedance
+4 dB (nominal)
20 kOhms (balanced)
A/D converters bit 24
D/A converters
bit
Dynamic range
Sampling Rate
24
100 dB
48 kHz
Crossover
Type
Frequency
Slope
Bessel, Butterworth or Linkwitz-Riley
Variable from 15.6 Hz t 16 kHz
6, 12, 18 o 24 dB/oct.
EQ
Number
Type
Gain
Bandwidth
Frequency
15 parametric bands
Peak, 6dB Lo-Shelf, 12dB Lo-Shelf, 6dB Hi-Shelf, 12dB Lo-Shelf, Notch
+/-15dB, variable with 0.5dB step
From 0.05 to 3.00 octaves, variable with 0.05dB step
From 15.6 Hz to 16 kHz
Alignment delay max delay 189 ms
Plugins Noise Gate, Multiband compressor
Protections
Independent PEAK LIMITER on each output
Long term power protection on each output
LFC - Low Frequency Control
Output power
EIA (1kHz, THD 1%)
W 500
Distortion % <0.02
Controls Volume - PRESET selector
Connections 2 x XLR-F + 2 x XLR-M
Power supply see label
Frequency response Hz (-10dB) 32 - 200
Sensitivity MAX SPL Continuous 125
SYSTEM SPECIFICATIONS
LOUDSPEAKER SPECIFICATIONS
T5SA • TECHNICAL SPECIFICATIONS
AMPLIFIER SPECIFICATIONS
