5
titanium series
1. Introduction
Congratulations for having chosen the TITANIUM
series of loudspeaker system!
To make the best use of the system, please read this
manual thoroughly before operating the equipment.
2. Contents
3. Instructions for use and installation . . . 5
1. Protection and maintenance. . . . . . . . . . . . . . . . 5
2. Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Connector cables . . . . . . . . . . . . . . . . . . . . . . . . 5
4. The TITANIUM series. . . . . . . . . . . . . . . . 5
5. Installation and connections . . . . . . . . . 5
1. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2. Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Connection panel . . . . . . . . . . . . . . . . . . 5
7. Technical specifi cations . . . . . . . . . . . . . 6
3. Instructions for use and installation
1. Protection and maintenance.
To avoid jeopardizing correct operation, it is best not
to position the enclosures for long periods in exposed
places (damp, high temperature, etc.), in dusty
environments or those subject to strong vibrations. On
this subject, it’s advisable to always leave the protective
grille mounted on the enclosures. In the event of
breakdown, do not open the enclosure, but contact the
nearest GENERALMUSIC Service Centre.
2. Connections.
Always connect or disconnect the enclosures with the
power amplifi er off: in this manner, annoying and often
dangerous peaks are avoided.
3. Connector cables.
When connecting the enclosures to the power amplifi er,
make certain to always use only power cables made
up of just two wires with the same cross-section: the
use of signal cables could cause an excessive loss of
power. Check periodically that your cables are in good
condition, correctly wired and with perfectly effi cient
contacts: in fact many problems and drawbacks (false
contacts, ground hum, crackles, etc.) are caused by the
use of unsuitable or damaged cables.
4. The titanium series (fi g. 1)
The TITANIUM series is range of passive loudspeaker
systems hosted in plywood cabinets. The series
includes 4 different models.
- T200: it is fi tted with a 1” horn-loaded compression
driver and with a 10” woofer, with a power handling of
200W EIA.
- T300: it is fi tted with a 1” horn-loaded compression
driver and with a neodymium magnet 12” woofer, with a
power handling of 300W EIA.
- T400: it is fi tted with a 1” horn-loaded compression
driver and with a neodymium magnet 15” woofer, with a
power handling of 400W EIA.
- T500: it is fi tted with a 1” horn-loaded compression
driver, a 8" midrange and a neodymium magnet 15”
woofer, with a power handling of 500W EIA.
All the models are equipped with carefully engineered
passive crossovers and with a sophisticated active
circuit for the protection of the drivers against power
overloading.
5. Installation and connections
1. Installation (fi g. 3)
All the TITANIUM series models are fitted with an
adapter for the installation on a standard loudspeaker
stand. In addition, in the models T200 and T300 four
fl ying points are provided, 2 on the top panel and 2 on
the bottom panel, for the installation of the unit using M8
threaded hardware or dedicated accessories.
IMPORTANT!!!
The threaded inserts allow only one T200 or T300 to
be suspended at a time, therefore THE SUSPENSION
OF MORE UNITS IN A SINGLE VERTICAL CLUSTER
IS NOT RECOMMENDED. In case this is needed,
don’t hang more than 2 units.
2. Connections
The TITANIUM loudspeaker systems are provided with
SPEAKON connectors for the connection to power
amplifi ers or powered mixers (see fi g.3).
The models T300, T400 e T500 in the 4ohm version are
fi tted with a single SPEAKON connector (INPUT).
The model T200 (available only with 8ohm impedance)
and the models T300, T400 e T500 in the 8ohm version
are fitted with an additional SPEAKON connector
(LINK) to be used to send the power to a second unit
connected to the same amplifi er's channel.
6. Connection panel (fi g. 4)
1. SPEAKON power input for the connection to the
power outputs of the amplifi er or the powered
mixer (INPUT). The SPEAKON connector wiring
diagram is printed on the enclosure connection
panel.
2. SPEAKON power output for the linking of two
loudspeaker systems to the same amplifi er or
powered mixer (LINK).
