LENCO L-90 - Stylus Replacement; Cartridge Disassembly; Cartridge Installation

24
How to replace the stylus
 Lock the tone arm.
 Remove the protective cap from the stylus.
 Pull the stylus in the direction of the arrow (A) and remove it.
 Put in the new stylus following the reverse procedure.
 Replace the protective cap on the stylus.
How to disassemble the cartridge
 Lock the tone arm.
 Remove the stylus (see section above).
 Release the pick-up head by pushing the cartridge in the
direction of the arrow.
 Disconnect the four wires at the level of the pick-up head.
How to install a new cartridge
 Connect the link wires.
 Push the cartridge into the head shell
 Re-position the stylus
 Place the protective cap on the stylus.
